E-SPVAC-I-0419
OPERATOR'S INSTRUCTION MANUAL
FOR
SLURRY PRO VACUUM
READ AND UNDERSTAND THE OPERATOR'S INSTRUCTION MANUAL
THOROUGHLY BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.
Death or serious injury could occur if this machine is used improperly.
EQUIPMENT DEVELOPMENT COMPANY, INC.
Printed in USA
©2019
JWA
100 Thomas Johnson Drive, Frederick, MD 21702-4600 USA
Phone: 800-638-3326 or 301-663-1600 • Fax: 800-447-3326 or 301-663-1607
1-800-638-3326
• edcoinc.com • techsupport@edcoinc.com
Website: www.edcoinc.com • E-mail: techsupport@edcoinc.com
Page 1
Advertisement
Table of Contents
Related Manuals for Edco SLURRY PRO VACUUM
Summary of Contents for Edco SLURRY PRO VACUUM
- Page 1 E-SPVAC-I-0419 OPERATOR’S INSTRUCTION MANUAL SLURRY PRO VACUUM READ AND UNDERSTAND THE OPERATOR’S INSTRUCTION MANUAL THOROUGHLY BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT. Death or serious injury could occur if this machine is used improperly. EQUIPMENT DEVELOPMENT COMPANY, INC. Printed in USA ©2019...
-
Page 2: Safety Information
E-SPVAC-I-0419 SAFETY INFORMATION SAFETY MESSAGES ELECTRICAL POWERED EQUIPMENT CONTINUED • Safety Instructions are proceeded by a graphic alert symbol of DANGER, • Do not disconnect power by pulling cord. To disconnect, grasp the WARNING, or CAUTION. plug, not the cord. •... -
Page 3: Table Of Contents
Safety Information ..........2 Safety - Specifically for the Slurry Pro Vacuum ......4 Features . -
Page 4: Safety - Specifically For The Slurry Pro Vacuum
CAUTION: Disconnect the machine from power before and during inspection or maintenance. When in use, this machine should always be connected to a ground fault interrupter (GFCI/GFI), either the circuit breaker or receptacle type. Use only EDCO replacement parts, accessories and hoses specifically designed for your machine. Clean unit daily. FEATURES Technical Key: 1. -
Page 5: Specifications
E-SPVAC-I-0419 SPECIFICATIONS 5/3/2019 SLURRY-VAC-DIMENSIONAL-2.26.19-WITH-FLOORSWEEP.png (2000×2000) DIMENSIONS 59.117” 50.685” 31.500” 1-800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 5... -
Page 6: Startup And Shutdown
III. Start-Up E-SPVAC-I-0419 SLURRY VAC INSTRUCTIONS: START UP / SHUTDOWN STARTUP AND SHUTDOWN Check that the slide Connect to proper Start machine using Turn machine off using valve is closed. power source as the ON / OFF switch the ON / OFF switch indicated on the on the motor domes. -
Page 7: Emptying
Inspection & Maintenance E-SPVAC-I-0419 SLURRY VAC INSTRUCTIONS: EMPTYING - Collection vessel and pump must be cleaned after every single use. The pump may be used while the vacuum is running, but if the pump needs to be cleaned you must turn the vacuum off. Use the internal pump If pump becomes Once most of the water... -
Page 8: Pump Cleaning Instrcutions
Inspection & Maintenance E-SPVAC-I-0419 SLURRY VAC INSTRUCTIONS: PUMP CLEANING INSTRUCTIONS PUMP CLEANING INSTRUCTIONS Loosen hose cuff. Disconnect clamps on Remove motordeck. Remove the pump either side. from the tank without disconnecting the hose. Place the pump in a 5 gallon bucket and run the clean water through the pump. -
Page 9: Filter Inspection
Inspection & Maintenance E-SPVAC-I-0419 SLURRY VAC INSTRUCTIONS: FILTER INSPECTION FILTER INSPECTION Disconnect the pump Remove motordeck Loosen filter hold down Disconnect clamps on from power if included. and inspect filter. The bracket bolts enough to either side. filter is used to stop remove the filter. -
Page 10: Motor Cover Disassembly For Brush Inspection
E-SPVAC-I-0419 Inspection & Maintenance SLURRY VAC INSTRUCTIONS: MOTOR COVER DISASSEMBLY FOR BRUSH INSPECTION MOTOR COVER DISASSEMBLY FOR BRUSH INSPECTION Turn the machine off, Disconnect motor Loosen the motor Remove the 6 screws then disconnect the terminal. retaining knobs attached to each motor power source. -
Page 11: Ametek Motor Brush Inspection
E-SPVAC-I-0419 Inspection & Maintenance SLURRY VAC INSTRUCTIONS: AMETEK MOTOR BRUSH INSPECTION AMETEK MOTOR BRUSH INSPECTION NOTE: A motor brush should be replaced if its length is less than 0.25 inches. Remove motor fan Remove the two Pull brush out from Remove brush from cover by pressing down screws securing the... -
Page 12: Electro Motor Brush Inspection
E-SPVAC-I-0419 Inspection & Maintenance SLURRY VAC INSTRUCTIONS: ELECTRO MOTOR BRUSH INSPECTION ELECTRO MOTOR BRUSH INSPECTION NOTE: A motor brush should be replaced if its length is less than 0.25 inches. Carefully dislodge the With a flathead If the brush is worn While holding spring plastic motor cap via screwdriver, flip brush... -
Page 13: Troubleshooting
E-SPVAC-I-0419 TROUBLESHOOTING Troubleshootin PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Insufficient Vacuum - Hose blocked - Unplug hose. - Filter clogged or improperly - Follow filter inspection procedure (Section IV) seated - Vacuum leak - Check that motor deck is properly seated and secured. - Page 14 E-SPVAC-I-0419 THIS PAGE LEFT BLANK INTENTIONALLY 1-800-638-3326 • edcoinc.com • techsupport@edcoinc.com Page 14...
-
Page 15: Limited Equipment Warranty Of Sale
*Seller reserves the right to alter payment terms. EDCO will, at its option, repair or replace, at the EDCO factory or at a point designated by EDCO, any part which shall appear to the satisfaction of EDCO inspection to have been 3. -
Page 16: Stop - Before Using This Product
EDCO product group. The information in these tracks help businesses be successful with those products. EDCO is always updating online training / information so you always have the most recent content. Also see Operator’s Safety & Limited Warranty Manual Equipment Development Co., Inc.
