Monitor Cable
Qty. 1
After unpacking the contents, inspect the shipment for any signs of damage or loss. If
any damages are discovered, notify the carrier, the supplier, and retain all shipping
cartons for examination.

Step 2: Attach the AC Power Supply

a. Remove the AC Power Supply from the package and connect the AC Power Supply
to the Hummingbird ICP Control Module.
i. Insert the plug end of the AC Power Supply into a grounded AC wall outlet.
ii. On the back of the Hummingbird ICP Control Module, attach the connector
end of the AC Power Supply into the AC Port.
P/N: 7000717 Rev A, CO-148, Released Date: 2021-01-28; ©2021, IRRAS USA, Inc., All rights reserved
AC Power Supply
Qty. 1
Page 9 of 38
ICP Control Module
Qty. 1
Patient Cable Module
Qty. 1
