In the field "Max Error" the number of consecutive errors that the Master waits before stopping the specific requests is defined;
In the field "Position" the starting byte of the internal memory array from which taking the data to write is defined;
The field "Start Bit" is used for the "Binary Output" BACnet objects. It is possible to select the bit in the byte from which taking the
data;
In the field "Mnemonic" a description of the data inserted in the row is defined.

ETHERCAT ESI FILE:

By pressing the "EtherCAT ESI
The ESI file is used to configure the EtherCAT Master.
ADFweb.com S.r.l.
File" button it is possible to save the ESI file for the EtherCAT side of the converter.
