Instructions for
installation and use
English,1
AQUALTIS
AQLF9F 49 U
WASHING MACHINE
Contents
Installation, 2-3-4-5
Auto Dose System, 8-9
Trouble shooting, 15-16
Assistance, 17-18
EN
1
Advertisement
Table of Contents
Related Manuals for Hotpoint AQUALTIS AQLF9F 49 U
Summary of Contents for Hotpoint AQUALTIS AQLF9F 49 U
-
Page 1: Table Of Contents
Instructions for installation and use WASHING MACHINE Contents Installation, 2-3-4-5 Unpacking and levelling Connecting the electricity and water supplies Technical data English,1 Description of the machine, 6-7 Control panel Auto Dose System, 8-9 Running a wash cycle, 10 Wash cycles and options, 11 Table of wash cycles Wash options Detergents and laundry, 12... -
Page 2: Installation
Installation This instruction manual should be kept in a safe place If the appliance is levelled correctly, it will be more for future reference. If the washing machine is sold, stable and much less likely to cause vibrations and noise given away or moved, please ensure the manual is kept while it is operating, particularly during the spin cycle. - Page 3 Connecting the drain hose • the supply voltage is included within the values i ndicated on the Technical details table (see page 5); Connect the drain hose, without bending it, to a • the socket is compatible with the washing draining duct or a wall machine's plug.
- Page 4 As the colours of the wires in the lead may not correspond with the coloured markings identifyng the terminals in your plug, proceed as follows: Connect Green & Yellow wire to terminal marked E or or coloured Green or Green & Yellow. Connect Brown wire to terminal marked L or coloured Red.
-
Page 5: Technical Data
Technical data Model AQLF9F 49 U width 59.5 cm Dimensions height 85 cm depth 64,5 cm Capacity from 1 to 9 kg Electrical please refer to the technical data connections plate fixed to the machine maximum pressure 1 MPa (10 bar) Water connections minimum pressure 0.05 MPa (0.5 bar) drum capacity 62 litres... -
Page 6: Description Of The Machine
Description of the machine CONTROL PANEL PORTHOLE DOOR PORTHOLE DOOR HANDLE KICK STRIP ADJUSTABLE FEET PORTHOLE DOOR Standby mode This washing machine, in compliance with new energy Always use the handle to saving regulations, is fitted with an automatic standby open the porthole door (see system which is enabled after about 30 minutes if no figure). -
Page 7: Control Panel
TEMPERATURE/ DETERGENT Control panel DELAY TIMER/SOFTENER / display CYCLE DURATION WASH display SPIN DETERGENT display CYCLE DILUTION SOFTENER PHASE indicator light button button icons START/PAUSE DETERGENT OPTION WASH CYCLE button button button with indicator with indicator light SELECTOR knob light CHILD LOCK button ON/OFF... -
Page 8: Auto Dose System
Auto Dose System Introduction Filling the tanks: This washing machine is Open the detergent dispenser drawer in the "Auto Dose equipped with two tanks: one System" mode (refer to "Detergent dispenser"). for liquid detergent (either Slowly pour the detergent (B) and fabric softener (C) concentrated or diluted) with until the tanks are completely filled (see picture). - Page 9 Signals for successive refilling: Automatic cleaning: When the level of detergent/fabric softener falls below the The washing machine carries out an automatic cleaning required level, at the end of the cycle, the first segment of cycle during the rinse cycle if the level of detergent that detergent symbol or the petal of the fabric remains is insufficient for carrying out a...
-
Page 10: Running A Wash Cycle
Running a wash cycle WARNING: before you use the washing machine for press the button until the display shows the text OFF; the first time, run a wash cycle with detergent and no symbol will disappear. laundry, using the 90° cottons cycle without pre-wash. Once the START/PAUSE button has been pressed, the time delay may only be decreased. -
Page 11: Wash Cycles And Options
Wash cycles and options Table of wash cycles Detergent and additives Max. Max. Max. Cycle Icon Description of the wash cycle temp. speed load duration Detergent Detergent Fabric (°C) (rpm) (kg) for prewash for wash softener Cottons wash cycles Cotton with pre-wash 90°... -
Page 12: Detergents And Laundry
We recommend the following: be folded and placed inside the bag provided. • Use powder detergent for carrying out a pre-wash Wool: Hotpoint is the only washing machine brand to and pour in the "traditional" mode. have been awarded the prestigious Woolmark Platinum •... -
Page 13: Precautions And Advice
Precautions and tips The machine was designed and constructed in For more information relating to the correct disposal of accordance with international safety regulations. The household appliances, owners should contact their following information is provided for safety reasons and local authorities or appliance dealer. -
Page 14: Care And Maintenance
Care and maintenance Cutting off the water and electricity To access the pre-chamber: supplies • Turn off the water tap after every wash cycle. This will limit wear on the hydraulic system in the machine and help to prevent leaks. •... -
Page 15: Trouble Shooting
Trouble shooting Your washing machine could occasionally fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be not solved easily using the following list. Problem: Possible causes / Solutions: The washing machine does not •... - Page 16 Troubleshooting: Possible causes / Solutions: The machine's washing • The tanks have not been loaded correctly (e.g. fabric softener has been performance is unsatisfactory. added instead of detergent or vice-versa) • Two different types of detergent/fabric softener have mixed. NEVER mix two different detergents; always clean out the tanks before adding a new type of detergent.
-
Page 17: Assistance
OR NON-DOMESTIC PREMISES. 5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. - Page 18 Republic of Ireland: 0818 313 413 www.hotpointservice.co.uk Appliance Registration We want to give you additional benefits of Hotpoint ownership. To activate your free 5 year parts guarantee you must register your appliance with us. UK: 08448 24 24 24 Republic of Ireland: 01 230 0800 www.hotpointservice.co.uk...
- Page 20 195078506.04 09/2009 - Xerox Fabriano...
