Instructions for installation and use WASHING MACHINE Contents Installation, 2-3-4-5 Unpacking and levelling Connecting the electricity and water supplies English,1 Technical data Care and maintenance, 6 Cutting off the water and electricity supplies Cleaning the machine Cleaning the detergent dispenser drawer Caring for your appliance drum Cleaning the pump Checking the water inlet hose...
Installation ! This instruction manual should be kept in a ! If the appliance is levelled correctly, it will safe place for future reference. If the washing be more stable and much less likely to cause machine is sold, given away or moved, please vibrations and noise while it is operating, ensure the manual is kept with the machine, particularly during the spin cycle.
Page 3
Connecting the drain hose • the socket is compatible with the washing machine’s plug. If this is not the case, replace Connect the drain the socket or the plug. hose, without bending it, to a Your appliance is now supplied with a 13 amp draining duct or a fused plug it can be plugged into a 13 amp wall drain situated...
As the colours of the wires in the lead may ! The power supply cable must only be not correspond with the coloured markings replaced by an authorised serviceman. identifying the terminals in your plug, proceed as follows: Warning! The company denies all liability if and Connect Green &...
Care and maintenance Cutting off the water and To access the pre-chamber: electricity supplies • Turn off the water tap after every wash cycle. This will limit wear on the hydraulic system in the machine and help to prevent leaks. •...
Precautions and tips ! The machine was designed and constructed in inside the machine, while preventing potential damage accordance with international safety regulations. The to the atmosphere and to public health. following information is provided for safety reasons and The crossed-out dustbin is marked on all products must therefore be read carefully.
Description of the machine CONTROL PANEL PORTHOLE DOOR PORTHOLE DOOR HANDLE KICK STRIP ADJUSTABLE FEET PORTHOLE DOOR Do not pour detergent into the compartment 1. Always use the handle to Detergent should only be open the porthole door (see poured into the compartment 2. figure).
Running a wash cycle WARNING: before you use the washing machine for the Modify the cycle settings. first time, run a wash cycle with detergent and no laundry, Press the OPTION buttons to customise the wash cycle using the 90° cottons cycle. in accordance with your own requirements.
Detergents and laundry end of the cycle, garments will be relaxed and fragrant. Detergent ! Not recommended for wool or silk garments. The type and quantity of detergent required depend on ! Do not add too much perfume to the sponge in order to the type of fabric you are washing (cotton, wool, silk, avoid it dripping.
Trouble shooting Your washing machine could occasionally fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. •...
Page 14
The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
Product Guarantee and Repair Information Guarantee Recycling and Disposal Information As part of Hotpoint’s continued commitment to 12 Months Parts and Labour Guarantee helping the environment, Hotpoint reserves the right Your appliance has the benefit of our manufacturer’s to use quality, recycled components to keep down guarantee, which covers the cost of breakdown customer costs and minimise material wastage.
