Servicing on the left-hand side of the
tractor
40. Mark and disconnect the feed hose on the steering
ram.
41. Remove the protection grille close to the radiator.
42. If necessary, disconnect the air sleeve (2) from the
cooler inlet (intake manifold inlet - Perkins EEM
engine - Fig. 19).
Draining the cooling system
43. Unscrew the wing plug located on the front
left-hand side of the radiator, to drain the circuit.
If the engine is hot, gradually loosen
the expansion tank plug and remove it in order
to release the pressure from the circuit.
44. Disconnect the lower radiator hose (1) and the
hose (2) linking the expansion tank to the base of
the radiator (Fig. 20).
Servicing above the engine
45. Disconnect the upper radiator hose (1) (Fig. 21 ).
Massey Ferguson 6400 - Issue 2
¤
H
Splitting - Front frame / Perkins engine
Fig. 19
Fig. 20
Fig. 21
02A01.11
