USERʼS MANUAL
Model No. PFTL14011.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-888-533-1333
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for ProForm PRO 2500 PFTL14011.0
Summary of Contents for ProForm PRO 2500 PFTL14011.0
- Page 1 All manuals and user guides at all-guides.com www.proform.com USERʼS MANUAL Model No. PFTL14011.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE;...
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decals may not be shown at actual size. PROFORM is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
16. To purchase a surge suppressor, see informed of all warnings and precautions. your local PROFORM dealer or call the tele- phone number on the front cover of this man- 3. Use the treadmill only as described. - Page 4 All manuals and user guides at all-guides.com 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.
-
Page 5: Before You Begin
All manuals and user guides at all-guides.com BEFORE YOU BEGIN Thank you for selecting the revolutionary ing this manual, please see the front cover of this man- PROFORM PRO 2500 treadmill. The PRO 2500 ual. To help us assist you, please note the product ®... -
Page 6: Part Identification Chart
All manuals and user guides at all-guides.com PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 7: Assembly
All manuals and user guides at all-guides.com ASSEMBLY • To hire a service technician to assemble this • To identify small parts, see page 6. product in your home, call 1-800-445-2480. • Assembly requires the following tools: • Assembly requires two persons. the included hex key •... - Page 8 All manuals and user guides at all-guides.com 2. Pull the Upright Wire (88) and the Base Ground Wire (100) through the indicated hole in the Base (105). Attach the Base Ground Wire (100) to the Base (105) with a #8 x 1/2" Ground Screw (10). Press the Grommet (101) into the square hole in the Base (105).
- Page 9 All manuals and user guides at all-guides.com 4. Hold the Left Upright (90) against the Base (105). Be careful not to pinch the wires. If necessary, position the Base Ground Wire (100) in the hole in the side of the Left Upright. Insert two 3/8"...
- Page 10 All manuals and user guides at all-guides.com 6. Remove the four 3/8" x 1" Screws (6) and 3/8" Star Washers (14) from the Handrail Brackets (89). Then, remove the Handrail Brackets from the Left and Right Handrails (92, 93). The Screws and Star Washers will be used in step 8.
- Page 11 All manuals and user guides at all-guides.com 9. Remove and discard the #10 x 3/4" Screws (3) from the Right Handrail (93) and the Left Handrail (not shown). Pulse Wire Hold the pulse assembly near the Right Handrail (93). Insert the pulse wire from the pulse assem- bly into the hole in the side of the Right Handrail Pulse Assembly...
- Page 12 All manuals and user guides at all-guides.com 12. With the help of a second person, hold the con- sole assembly near the Uprights (90, 99). Console Assembly Connect the Upright Wire (88) to the console wire. See the inset drawing. The connectors should slide together easily and snap into place.
- Page 13 All manuals and user guides at all-guides.com 14. Attach a Tray Bracket (91) to the side of the Right Upright (99) with two #8 x 3/4" Screws (2). Make sure to use the two holes shown. Start both Screws, and then tighten them. Attach the other Tray Bracket (not shown) to the Left Upright (not shown) in the same way.
- Page 14 All manuals and user guides at all-guides.com 17. Attach the upper end of the Storage Latch (65) to the Frame (64) with a 3/8" x 1 3/4" Bolt (7) and a 3/8" Nut (13). Note: It may be necessary to move the Frame back and forth to align the Storage Latch with the Base (not shown).
-
Page 15: The Chest Heart Rate Monitor
All manuals and user guides at all-guides.com THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sunlight for extended periods of time; do not expose The heart rate it to temperatures above 122°... -
Page 16: Operation And Adjustment
All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets and may not be compatible Your treadmill features a walking belt coated with high- performance lubricant. - Page 17 All manuals and user guides at all-guides.com CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can also listen to your favorite workout music or audio books with the consoleʼs premium stereo sound The treadmill console offers an impressive array of system while you get in shape. features designed to make your workouts more effec- To turn on the power, see page 18.
- Page 18 All manuals and user guides at all-guides.com HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power.
- Page 19 All manuals and user guides at all-guides.com If you press one of the numbered Quick Speed but- • The distance that you have walked or run tons, the walking belt will gradually change speed until it reaches the selected speed setting. To se- •...
- Page 20 All manuals and user guides at all-guides.com To measure your heart rate, stand on the foot To reset the console, press the iFit Menu button in rails and hold the metal contacts on the the upper right corner of the screen. To pause the handrails—avoid moving your hands.
- Page 21 All manuals and user guides at all-guides.com HOW TO USE A SET-A-GOAL WORKOUT The workout will function in the same way as the manual mode (see pages 18 to 20). 1. Insert the key into the console. The workout will continue until you reach the goal See step 1 on page 18.
- Page 22 All manuals and user guides at all-guides.com HOW TO USE A CALORIE BURN WORKOUT OR also show the distance of your workout and the AN ALL-TERRAIN TRAILS WORKOUT number of vertical feet you will climb. In addition, the screen will show a topographic map of the trail. 1.
- Page 23 All manuals and user guides at all-guides.com 5. Monitor your progress. The workout will continue in this way until the last segment ends. The walking belt will then slow to a stop, and a workout summary will appear on the See step 5 on pages 19 and 20.
- Page 24 All manuals and user guides at all-guides.com HOW TO USE THE IFIT LIVE MODE THE COOL-DOWN MODE The iFit Live mode enables the treadmill to communi- To select the cool-down mode, press the Cool Down cate with your wireless network. With the iFit Live button.
- Page 25 All manuals and user guides at all-guides.com HOW TO USE THE SETTINGS MODE To use encryption, press the Use Encryption but- ton. Select the encryption type and enter the pass- The console features a settings mode that allows you word. When you are finished, press the Submit to connect your treadmill to your own wireless network button.
- Page 26 All manuals and user guides at all-guides.com 3. Log in to your iFit Live account. Press the US/Metric button to view the selected unit of measurement. Change the unit of measure- Press the iFit Live Login button. Then, enter your ment, if desired.
- Page 27 All manuals and user guides at all-guides.com HOW TO USE THE MAINTENANCE MODE press the Begin button, the treadmill will automati- cally rise to the maximum incline level, lower to the The console features a maintenance mode that allows minimum incline level, and then return to the start- you to calibrate the incline and speed of the treadmill, ing position.
- Page 28 All manuals and user guides at all-guides.com 6. Calibrate the speed of the treadmill. 8. View technical information. Stand on the foot rails or stand on the floor. Press the Technical Info button to view the total Press the Calibrate Speed button and then press number of hours that the treadmill has been used the Begin button.
-
Page 29: How To Fold And Move The Treadmill
All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to 0 percent before you fold the treadmill. -
Page 30: Troubleshooting
All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following c. Remove the key from the console, and then the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. - Page 31 All manuals and user guides at all-guides.com SYMPTOM: The iFit Live mode does not function Lower the treadmill (see HOW TO LOWER THE correctly TREADMILL FOR USE on page 29). Remove the three #8 x 3/4" Screws (2). Carefully pivot the Motor Hood (72) off.
- Page 32 All manuals and user guides at all-guides.com SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first re- when walked on move the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller screws a.
-
Page 33: Exercise Guidelines
All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 34: Part List
All manuals and user guides at all-guides.com PART LIST Model No. PFTL14011.0 R0411A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Walking Belt #8 x 3/4" Screw Platform Cushion Bracket #10 x 3/4" Screw Walking Platform 5/16"... - Page 35 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description Grommet Console Front Base Pad Console Frame Left Wheel Cap Console Clamp Wheel Console Ground Wire Base Cable Tie Heart Rate Strap Right Handrail Cover Heart Rate Sensor Left Handrail Cover Console Base...
-
Page 36: Exploded Drawing
All manuals and user guides at all-guides.com EXPLODED DRAWING A Model No. PFTL14011.0 R0411A... - Page 37 All manuals and user guides at all-guides.com EXPLODED DRAWING B Model No. PFTL14011.0 R0411A...
- Page 38 All manuals and user guides at all-guides.com EXPLODED DRAWING C Model No. PFTL14011.0 R0411A...
- Page 39 All manuals and user guides at all-guides.com EXPLODED DRAWING D Model No. PFTL14011.0 R0411A...
-
Page 40: Ordering Replacement Parts
All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
