Model No. PFTL29020
Serial No.
Write the serial number in the
space above for future reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for ProForm PFTL29020
Summary of Contents for ProForm PFTL29020
- Page 1 Model No. PFTL29020 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ - Page 3 SAVE THESE INSTRUCTIONS The decals shown have been placed on your treadmill. If a decal is missing, or if it is not legible, please call our Customer Service Department, toll-free, to order a free replacement decal (see ORDERING REPLACEMENT PARTS on the back cover of this manual).
-
Page 4: Before You Begin
The model number of the treadmill is PFTL29020. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the location). -
Page 5: Assembly
This is a nor- mal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. - Page 6 3. Insert a Plastic Shim (9) into each side of the post on the right side of the Base (38). Next, orient the Right Upright (15) as shown, and insert it into the Base. Make sure that the Wire Harness (53) does not fall into the Right Upright.
- Page 7 3 and 4. Then, lower the frame to the floor. 10.Make sure that all parts used in assembly are properly tightened before you use the treadmill. Keep the included allen wrenches in a secure place for adjustment purposes (see page 13). To protect the floor or carpet, place a mat under the treadmill.
-
Page 8: How To Plug In Power Cord
(see drawing 1 at the right). To purchase a surge sup- pressor, see your local PROFORM dealer or call 1-800-806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). -
Page 9: Battery Installation
• Do not stand on the walking belt when turning on the power. • Always wear the clip (see the drawing below) while using the treadmill. When the key is BATTERY INSTALLATION The console requires two "AA"... - Page 10 There are four incline levels. Before changing the incline, remove the key and unplug the power cord. Next, fold the treadmill to the storage position (see HOW TO FOLD THE TREAD- MILL FOR STORAGE on page 10).
-
Page 11: How To Fold And Move The Treadmill
HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the pin. Slowly release the latch knob. -
Page 12: Maintenance And Troubleshooting
PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see 1. c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in. - Page 13 1/2 of a turn. Be careful not to overtighten the walking belt. Plug in the power cord, insert the key and run the treadmill for a few minutes. Repeat until the walking belt is centered. b. If the walking belt slips when walked on, first remove the key and UNPLUG THE POWER CORD.
-
Page 14: Conditioning Guidelines
If your goal is to burn fat, adjust the speed and incline of the treadmill until your heart rate is near one of the lower two numbers in your training zone. -
Page 15: Exercise Frequency
Training Zone Exercise After warming up, increase the intensity of your exer- cise until your pulse is in your training zone for 20 to 60 minutes. (During the first few weeks of your exer- cise program, do not keep your pulse in your training zone for longer than 20 minutes.) Breathe regularly and deeply as you exercise—never hold your breath. -
Page 16: Ordering Replacement Parts
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAWING in the center of this manual) PROFORM is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase. -
Page 17: Part Identification Chart
PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Star Washer (2)–6 5/16” Star Washer (101)–4 3/4” Screw (5)–10 1” Tek Screw (31)–4 U-Nut (10)–4 Handrail Bolt (1)–4 1”... - Page 18 PART LIST—Model No. PFTL29020 Key No. Qty. Description Handrail Bolt Star Washer Handrail Spacer Handrail 3/4” Screw Key/Clip Frame Guide Incline Leg Shim U-nut Console Battery Cover Reed Switch Left Upright Right Upright 1” Bolt Cage Nut Motor Belt Motor Tension Bolt...
- Page 19 EXPLODED DRAWING—Model No. PFTL29020 R1102A...
