Teltronics SEB NET-PATH Installation And Operation Manual page 76

Serviceable Components
Table 5-1:NET-PATH Jumper Settings
J22
J28 - J35
J36 - J43
J44 - J51
J52 - J59
Page 5-6
Modules Present
Contact Sensors 1-8 RS232 (normal voltage)
Contact Sensors 1-8 RS423 (low voltage)
Contact Sensors 1-8 RS232 (normal voltage)
Contact Sensors 1-8 RS423 (low voltage)
Contact Sensors 9-16 RS232 (normal voltage)
Contact Sensors 9-16 RS423 (low voltage)
Contact Sensors 9-16 RS232 (normal voltage)
Contact Sensors 9-16 RS423 (low voltage)
Note See "Contact Sensor Strap Options"‚ page 2-8 for
more information about jumper settings.
