Introduction

Determining the
NET-PATH
Model
NET-PATH
Model Structure

Description and Specifications

NET-PATH is available in several configurations. All standard models include:
• 8 serial ports, 1 NIC
• 1 56K BPS modem
• 16 contact sensors
• 2 output relays (available through RJ45 connector)
• 1 DC voltage sensor (requires optional external cable)
• 2 temperature sensors, one internal, one external (external sensor requires addi-
tional equipment)
• integrated UPS
• LCD display panel
• audible alarm
• basic event processing software including Python script execution
Configuration variables include four RS232 ports, eight contact sensors, and SNMP
Segment Management software, AC or DC input power.
The serial number and model information is on a label attached to the bottom of the
unit.
Figure 1-1 shows how to use the model number to determine basic hardware
functions. The figure shows model 43308-U2OSA, which includes four serial ports, a
North American modem, 20 MB of memory, and networking with management for
twenty network elements.
