TM
JGP979BEF/SEF/WEF – GE Profile
Installation Information (in inches)
Tie down bolt
on each end
Blower can be swiveled 90
Blower assembly
clearance 15-5/8"
15/16"
Min. clearance
2" minimum
clearance
required
between
cooktop
and each
side wall
Select appropriate
duct cutout
(see ducting installation instructions.)
Specification Created 1/03
30" Built-In Downdraft Gas Modular Cooktop
30
21-3/4
Pressure regulator
Wiring box cover
Grease
container
21
29
7-9/16
9-3/8
13
1-7/8"
Min.
BTU's (000's) Natural Gas*
Right side (burners)
10.0
Grill Unit
8.0
*JGP979 cooktop is factory set for natural gas. It is not
LP convertible.
Note: Shipped with sealed gas burner module, right side. Left side accepts
optional modules that must be ordered and are available at additional cost.
Optional Modules (Available at additional cost)
Two-Burner Gas Module (sealed burners) –
JXGB79W – White on white
JXGB79B – Black on black
Gas Grill Module – JXGG79
Griddle – JXGL79
(use with optional Grill module)
Grill Cover –
JXGC89W – White on white
JXGC89B – Black on black
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
For answers to your Monogram,
®
GE Profile
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center
®
service, 800.626.2000.
or
