INSTALL THE RANGE

REPLACE THE WIRE COVER
8
Replace the terminal block cover on the
range back by replacing the screw removed
earlier. Make sure that no wires are pinched
between the cover and the range back.
Back of range
Terminal
block cover

ANTI-TIP DEVICE INSTALLATION

9
An Anti-Tip bracket is supplied with
instructions for installation in a variety of
locations. The instructions include all
necessary information to complete the
installation. Read the Safety Instructions
and the instructions that fit your situation
before beginning installation.
Screw must
enter wood
or metal
Typical installation of anti-tip bracket attachment to wall
WARNING:
• Range must be secured by Anti-Tip bracket
supplied.
• See instructions to install (supplied with bracket).
• Unless properly installed, the range could
be tipped by stepping or sitting on the door.
Injury may result from spilled hot liquids
or from the range itself.
Installation Instructions
Screw to
replace
terminal
block cover
Wall plate
Bracket
PREPARE TO LEVEL MODELS
10
A Measure the height of your countertop
at the rear of the opening (X).
Adjust two rear leveling legs so that the
B
rear of the cooktop (Y) is at the same
height as the counter (X).
Slide unit into place.
C
8
X
Y
