PREPARE THE OPENING

2
See illustrations for all rough-in and spacing
dimensions.
The range may be placed with 0" clearance
(flush) at the back wall and side walls of
the cabinet.
Acceptable electrical
outlet area.
Orient the electrical
receptacle so the length
is parallel to the floor.
30"
NOTE: Use a 4' power cord to prevent
interference. Power cords 4
may have to be dressed to allow for
proper installation.
Installation Instructions
3 "
1 ⁄
4
23 "
1 ⁄
2
3 1
47"
7
36"
25 3 ⁄ "
8
45"
⁄ to 6' long
1
2
**15" Min.
⁄ "
4
*0"
MINIMUM DIMENSIONS BETWEEN COOKTOP,
3 ⁄ "
4 WALLS AND ABOVE THE COOKTOP:
*** Make sure the wall covering, countertop,
flooring and cabinets around the range
can withstand the heat (up to 200°F)
generated by the range.
*** Allow 30" minimum clearance between
surface units and bottom of unprotected
wood or metal cabinet, and 15" minimum
between countertop and adjacent cabinet
bottom.
*** Recommended spacing to heat-sensitive
surfaces.
3
**30" Min.
***6"
Min.
*0"
