Trace Engineering RC7 Manual page 13

Inverter-Charger Current
Displays the actual current (not an average) passing through the inverter to AC loads when
an AC supply is available, or provided by the inverter when inverting.
AC Input Voltage
This meter displays the actual AC voltage and peak AC voltage supply to the
inverter/charger, measured at the AC Input Hot 1 terminal.
AC Output Voltage
Displays the actual AC Voltage output of the inverter/charger measured at the AC Output
Hot 1 terminal.
AC Input Amps
Appears only on the RC7GS display. Measures the actual AC amperes passing through
the AC Input Hot 1 terminal.
Pass Through Amps
Appears only on the RC7. D
inverter/charger when an external AC source is supplied. Measured at the AC Input Hot 1
terminal.
Battery Temperature
This meter displays the external temperature of your battery or battery bank when equipped
with a Battery Temperature Sensor (BTS). The scale is divided into counts, which do not
directly correspond to the Fahrenheit or Celsius temperature scale. A higher reading
indicates a lower temperature.
©
Copyright Trace Engineering Co. Inc.
t h
5916 195 Street, NE
Arlington, WA 98223 USA
Inv/Chg Current:
+/- 0 Amps DC
AC Input
000 Vac 000 Vpk
AC Output:
000 Vac
AC Input:
0 Amps AC
isplays the actual AC amps passing through the
Pass-thru Amps:
0 Amps AC
Battery Temp
000 counts
