Select Genset; Generator Start; Generator Stop - Trace Engineering RC7 Manual

When the cursor is under the hour character, press the Settings key to increment the hours.
Repeat to set the minutes. Press and hold the Settings key to increment the values
quickly, or press and release the settings key to increment the value by one unit.

Select Genset

After setting the RC7GS's internal clock, press the Up arrow key to display the Select
Genset menu item. Press the Settings key until the name and model of your generator is
displayed (not all generators are supported). Then press an arrow key to scroll to the next
menu item. The menu selections are shown below:
Select Genset: Select Genset:
Onan QuietDiesel Other 10
Default

Generator Start

After set setting the clock and
automatically starting and stopping the genset based upon battery voltage or state-of-
charge. Scroll through the Setup Menu until the Generator Start menu is displayed. Press
the Settings key until the desired setting is displayed. Then go on to another menu. The
setting will take effect 20 seconds after you exit the Setup Menu if no other action is taken.
Generator Start: Generator Start:
Manual (Push On) Auto at 40% SOC
Default
The default generator Start selection is "
automatic start functions. Any other selection from the Generator start menu will enable
the RC7GS to automatically start the generator based upon battery state-of-charge or
voltage.
You can start or stop the generator set at any time by pressing the Down arrow key on the
User Menu until the screen shown below is displayed, then pressing the On/Off button on
the RC7GS faceplate until the generator starts or stops. Release the On/Off key as soon as
the generator starts. If the inverter/charger senses an AC supply while the remote control
On/Off button is pressed, it will shut down the generator.

Generator Stop

You can configure the RC7GS to shut down the generator automatically when the batteries
reach 90 to 99% SOC, or when the charger initiates the Absorption or the Float stage of
charging. Refer to your inverter/charger Owner's Manual for a detailed discussion of
charging stages. The Generator Stop menu selections are shown below; the default setting
is 'Manual (Push Off)." You can stop the generator manually at any time by scrolling
©
