Instruction Revision: C
S
(042,059) 48In & 60In Salem Dining Tables rev. C
Parts List:
(1) Table Top Assembly
(2) Leg Assemblies
(2) Leg Stretchers
(2) Long Aprons
(2) Short Aprons
READ ENTIRE INSTRUCTIONS BEFORE BEGINNING! Carefully remove contents
from box. Make sure that all parts and hardware are included.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
C
EASIDE
ASUAL
ENVIRO
Assembly Instructions
Step One: Set Up
Step Two: Leg Stretcher Assembly
Place Leg Stretcher in between both Leg Assemblies.
Align pre-drilled holes on Leg Stretcher to Leg Assem-
blies. Attach using (2) 3" Hex 1/4" Lags (Left Picture).
Repeat process on all sides.
Step Three: Apron Assembly
F
URNITURE
WOOD
Attach Short Apron to Long Apron using (4) 3"
Hex 1/4" Lags (Left Picture).
1
Hardware:
(16) 3" Hex 1/4" Lags
(10) 3/4" Pan Head Screws
(59 Only) (18) 3/4" Pan Head
Screws
Tools Required:
Phillip's Head Screwdriver
4MM Allen Wrench (Included)
Advertisement
Table of Contents
Related Manuals for SEASIDE CASUAL FURNITURE Salem 042
Summary of Contents for SEASIDE CASUAL FURNITURE Salem 042
- Page 1 Instruction Revision: C EASIDE ASUAL URNITURE ENVIRO WOOD (042,059) 48In & 60In Salem Dining Tables rev. C Parts List: Hardware: (16) 3” Hex 1/4” Lags (1) Table Top Assembly (10) 3/4” Pan Head Screws (59 Only) (18) 3/4” Pan Head (2) Leg Assemblies Screws (2) Leg Stretchers...
- Page 2 Step Four: Base Assembly Place Apron Assembly on to the Leg Assembly and secure using (4) 3“ Hex 1/4” Lags (Right Picture) Step Five: Final Assembly Lift Base Assembly and place square on to table top. Align Apron ends and sides to the center of the table top. Attach ta- ble top to the base using (10) 3/4”...
