Westomatic Primo Compact Install, Clean & Fill

Fresh milk
Hide thumbs Also See for Primo Compact:

Advertisement

Quick Links

Download this manual
FRESH MILK
I N S T A L L , C L E A N & F I L L

Advertisement

loading
Need help?

Need help?

Do you have a question about the Primo Compact and is the answer not in the manual?

Questions and answers

Related Manuals for Westomatic Primo Compact

Summary of Contents for Westomatic Primo Compact

  • Page 1 FRESH MILK I N S T A L L , C L E A N & F I L L...
  • Page 2 INSTALL MILK FRIDGE The milk fridge is designed to work in combination with the Primo Compact: External Dimensions Fridge: W230xD420xH455mm External Dimensions Total: W530xD515xH600mm Capacity Milk Fridge: 4litres/8pints fresh milk Noise Emission: <70dB Weight: 19kg (Total: 57kg)

  • Page 3: Parts Included

    OPTIONAL: Ingredient Box PN: 1057339 NB: The machine will have been set up to your specifications and tested at Westomatic HQ prior to install. All parts have been assembled on the machine. The QR code inside the machine gives access to the We:Support pages with technical information.
  • Page 4 Place the Fridge Connect milk on a level surface hose to milk Min Clearances: output - feed Rear: 50mm hose through into fridge Ensure the Clean milk fridge, protective place hose in plastic is milk container, removed from place in machine the top and close door Move fridge...
  • Page 5 Connect fridge to a 230V mains power socket - ensure supply has minimum 45W Switch the Fridge on using button on the front Machine is ready to use...

  • Page 6: Parts Needed

    Parts Needed:...
  • Page 7 FRESH MILK CLEANING: These instructions show the steps for Cleaning the Fresh Milk Fridge: The Fresh Milk Fridge must be cleaned every day The Primo will remind you to clean the fridge at a pre-set time each day - the machine won't work unless this is done...
  • Page 8 Before you Clean the start - wash canister with hands or wear dishwasher gloves detergent Rinse with Open the milk thoroughly cooler, remove clean water the hose and wipe clean Ensure you Empty the milk clean the lid canister thoroughly with detergent too...
  • Page 9 FRESH MILK LINE CLEANING: These instructions show the steps for Cleaning the Fresh Milk Lines: For this process you will need: Westomatic Milk Line Cleaner Measuring Jug Fresh Water Cleaning wipes...
  • Page 10 NEXT screen Select CLEAN Fill a measuring MILK SYSTEM jug with 500ml Follow machine of clean water instructions Use 30ml of Before you Westomatic start - wash Milk Line hands or wear cleaner. Press gloves NEXT on screen...
  • Page 11 Place the hose in Empty the the jug and press container NEXT on the screen Place container Replace under the outlet - container back Hot water is under outlet dispensed - press and press NEXT NEXT on screen on screen System cleans Remove and the lines - This...
  • Page 12 Clean the System cleans measuring jug the lines - This with dishwasher takes about 4 detergent minutes - Hot water dispensed Fill measuring Remove the jug with 1 litre container, of clean water press NEXT on the screen Place the hose The cleaning in the jug, and process is stored...
  • Page 13 Clean the milk Clean drip tray container with using a damp dishwasher cloth detergent Place milk Machine is container back ready to use into fridge with hose Clean drip tray and cover behind...
  • Page 14 FRESH MILK FILLING: These instructions show the steps for Filling the Fresh Milk Fridge: Ensure the Fresh Milk Fridge and lines are clean Clean the Fridge before every refill Clean the Lines daily after use...
  • Page 15 Press menu to Open fridge, start remove milk container and Fill the Select Fill Milk, container with the system will cold milk - max start filling, 8 pints/4 litres follow on screen Press NEXT instructions Replace the lid Before you on the start wash your container, and...
  • Page 16 Place Fridge back Remove the into machine, container - close the door press NEXT and press NEXT Place empty The milk container under system is ready the outlet - press to use. Press X NEXT on screen (close) to go to recipe menu The machine All drinks with...
  • Page 17 CONTACT + 4 4 ( 0 ) 1 6 2 6 3 2 3 1 0 0 W e s t o m a t i c V e n d i n g S e r v i c e s L t d , s a l e s @ w e s t o m a t i c .
