Costway TQ10042 User Manual

Kids battery-powered ride on car
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TQ10042 and is the answer not in the manual?

Questions and answers

Related Manuals for Costway TQ10042

Summary of Contents for Costway TQ10042

  • Page 2 Battery-Powered Ride On Car TQ10042...
  • Page 3 Please read all instructions carefully and keep it for future reference. Warnings: Attention! Use it with protective equipment. Attention! Not use it in the traffic. Attention! The product is not suitable for the children under 3 years. General Warnings: The product must be installed and used under the supervision of an adult. Read through each step carefully and follow the proper order.
  • Page 4 Mercedes-AMG G63 Licensed Battery-Powered Ride-on Styles and colo(u)rs may vary ◎Suitable age for 3+ Years ◎Maximum user weight: 130 lbs. ◎Adult assembly required OWNER’S MANUAL with Assembly Instructions Read and understand this entire manual before using! Please keep this manual for future reference as it contains important information. Before first time use, charge the battery for at least 4-6 hours.

  • Page 5: Specification

    About New Vehicle On the purchase of your new Ride-On “Mercedes-Benz”, and the design of the enclosed product are subject to intellectual property protection owned by Daimler AG. They are used by Pinghu Little Sun Childs Vehicles CO.,LTD Trademarks, design patents and copyrights are used with the approval of Mercedes- AMG G63 Specification 37-96months...

  • Page 6: Parts List

    Parts List Number Name Quantity Two motor Front bumper/Front bumper trim Windshield Seat Steering wheel Car window Rearview mirror Trunk Tailstock Rear bumper Rear axle Driving motor Wheel front/rear Wheel cap Remote Control Charger Wrench Foot pedal Ø12 gasket M10 nut M4×12 screw M4×16 screw M5 screw...
  • Page 7 Two motor Pa ts Diagram...

  • Page 8: Choking Hazard

    PREVENT INJURIES AND DEATHS: ●NEVER LEAVE CHILD UNATTENDED.ADULT DIRECT Always keep child in view when SUPERVISION IS REQUIRED. child is in vehicle. ●This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties. ●Protective equipment should be worn.
  • Page 9 Oper tion Instruction Install front bumper trim (Optional) Insert the front bumper trim into the slots.
  • Page 10 Operation Instruction Install the front bumper (Optional) 1. Insert the buckle of the front bumper into the slot as shown in the arrow. Turn the body upside down. 2. Fix the front bumper and the front bar as shown in the arrow with M4*12 screw (short).
  • Page 11 Operation Instruction Install the steering wheel & trunk 1.Remove the nut and bolt from the steering wheel.Connect the wires coming from the steering column to the wires on the steering wheel.Insert the steering wheel over the steering column and secure with nut and bolt. 2 Install the trunk on the back of car body as picture shown，...
  • Page 12 Operation Instruction Install the windshield & tailstock 1.Clip the windshield into the hole of the car body， fixed it with M4*12 screw(short). 2.Fixed the tailstock into the back of car body， fixed it with M4*12 screw(short).
  • Page 13 Operation Instruction Install the window & rearview mirror 1. Clip the car window into the door，fixed with M4*16 screw(long). 2. Clip the rearview mirror into the car window. Install the other side window in the same way.
  • Page 14 Operation Instruction Install the foot pedal 1. Install the foot pedal to the designated position on the body 2. Fix with M4 * 12 flat head screw Install the other side in the same way Note: Foot pedals distinguish left and right...
  • Page 15 Operation Instruction Install the drive motors & wheels 1. Insert the rear axle into the car. 2. Put the drive motor into the rear axle, and stuck the motor into the body slot.
  • Page 16 Operation Instruction Put the gasket, Front wheel, gasket and nut into the front axle in turn. Fix the nut with the M10 wrench and then attach the wheel cover to the wheel Place the Rear wheel, gasket , and nut on the rear axle in turn. Fix the nut with the M10 wrench and then attach the wheel cover to the wheel.
  • Page 17 Operation Instruction Place the rear bracket as shown and fix it with the M4 * 12 screw(short): Put the car upside down Locate the main power cord under the seat, and insert the plug of the power cord into the corresponding socket of the receiver. The plug of the drive motor cable is docked with the plug on the receiver (the plug on the receiver does not distinguish between left and right).
  • Page 18 Operation Instruction Install the seat 1.Fix the upper cover seat into the corresponding buckle groove . 2.Clip the lower cover cushion flat into the upper cover cushion chuck.Fixed it with M4 16 screw(long).

  • Page 19: Function Instruction

    Function Instruction 1 ） Foot pedal: press down the pedal, the vehicle moves, lifting the foot to release the pedal, the vehicle will slowly brake. 2）Shift switch: Change the direction of the car , Forward-Stop-Backward. 3）Horn sound button: Press it for horn sounds . 4）Control board.
  • Page 20 Function Instruction 5)USB 6)Power display: Clearly see the battery power, in order to charge. 7)Socket: charge. 8)Light button : Turn on or off the light. 9)Last song：Switch songs, and long press will decrease volume. 10)Music button: Play music. 11)Next song: Switch songs, and long press will increase volume. 12)Power button: Long Press it for 3 seconds, turn the vehicle on and off;...
  • Page 21 Use the Remote Control WARNING! Only adults are allowed to use the remote control, and children are not allowed to touch it. Operation manual: frequency binding is required for the first use (or after replacing the battery). 1. Take out the remote control, lift the battery compartment door on the back of the controller and insert two AAA batteries.
  • Page 22 Charging 1.Insert the charger jack into the charging hole of the car. 2.Plug the charger plug into the stable matching AC power supply as shown in the picture. ATTENTION: Only an adult can charge and recharge the battery!
  • Page 23 Charging ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING!  PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or charger with another brand. Using another battery or charger may cause a fire or explosion.

  • Page 24: Battery Replacement And Disposal

    Battery Replacement Protector This product is equipped with self-resetting protector, when overloaded or improper use, self-resetting protector will automatically cut off the power supply for 15-20 seconds, and then restart. The self-resetting protector of the car is installed under the seat.
  • Page 25 Battery Replacement  Vehicles should be placed far away from fire sources and avoid long-term illumination. Keep it flat and facing upwards, not upside down or tilted; in wet weather, parked indoors or covered with waterproof cloth.  Vehicles should be kept away from hot objects such as stoves and heaters. Plastic parts may melt.

  • Page 26: Troubleshooting Guide

    Troubleshooting Guide 1.Is the No，change button；Yes，next acoustooptic switch good? The car can move 2.Check whether but there is no No，plug in the plug-in and connect the line and sound or light. the broken line plug-ins from battery to vehicle are good. 1.Is the drive Yes，Land the wheel；No，next rotating?

  • Page 27: Fcc Statement

    FCC Statement Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference. (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 28 Welcome to visit our website and purchase our quality products! With your inspiring rating, COSTWAY will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! US office: Fontana, California UK office: Ipswich Reward Points Exclusive Customer Service Personalized Recommenda�ons...
