Summary of Contents for Costway TQ10025
- Page 1 Toddler Ride On Scooter TQ10025...
- Page 2 Please read all instructions carefully and keep it for future reference. General Warnings: Danger! Keep all small parts and packaging materials for this product away from babies and children, otherwise they may pose a choking hazard. The product must be installed and used under the supervision of an adult. Read through each step carefully and follow the proper order.
-
Page 3: Specifications
Owner’s Manual with Assembly Instructions Styles and colo(u)rs may vary. Made in China. The owner’s manual contains important safety information as well as assembly, use and maintenance instructions. The Ride-on Car must be assembled by an adult who has read and understands the instructions in this manual. -
Page 4: User Notice
User Notice │ 2 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 18 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED. • Always remove protective material and poly bags and dispose before assembly. -
Page 5: Parts Diagram
Parts Diagram │ 3... -
Page 6: Parts List
Parts List │ 4 PART PART NAME Q’ty (pcs) REMARKS Vehicle body Steering column Steering wheel M5x30 machine screw Ø5 nut Rear handle Seat Ø4x12 screw Ø10 washer Snap ring Assembly tools required (not included): Magnetic screwdriver... - Page 7 Attach the Steering Column │ 5 Front Bottom View Turn the vehicle body on its side. Ø10 washer onto the straight end of the steering column. 1. Fit a 2. Insert the straight end of steering column up through the hole on the steering driver from bottom side, and out through the hole on the dash.
- Page 8 Attach the Steering Wheel & Insert the Batteries │ 6 Remove the M5x30 machine screw and Ø5 from the steering wheel. Turn the vehicle body upright. 1. Place the steering wheel over the the steering column, protruding from the middle of the steering wheel base.
- Page 9 Attach the Seat & Rear Handle │ 7 1. Fit the tabs on the seat into the holes on vehicle body. 2. Fit the rear handle into the groove on the back of the vehicle body. 3. Turn the vehicle body on its side. Tighten two Ø4x12 screw through the vehicle body and into the rear handle with a Magnetic screwdriver.
- Page 10 Use Your Ride-on │ 8 IMPORTANT When not using, please turn the audio player off, avoid to reduce the battery life. 1. Sound buttons: Press for sounds playing. 2. Volume knob: Turn the audio player on and off, +/- the volume. 3.
-
Page 11: Battery Disposal
Maintaining │ 9 • It is parents' responsibility to check main parts of the toy before using, Must regularly examine for potential hazard, such as the battery, charge, cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed. - Page 12 Welcome to visit our website and purchase our quality products! With your inspiring rating, COSTWAY will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! US office: Fontana, California UK office: Ipswich Reward Points Exclusive Customer Service Personalized Recommenda�ons...
