3.1.6.3 DESCRIPTION OF THE SWITCHES
Equipment 0
Name
SW1 and SW2
SW3
Name
SW and SW2
SW3
SW4 and SW5
Equipment 1
Name
SW6 and SW7
SW8
SW9 and SW10
