IMPAX-SK 5
IMPAX-SK 5
Operation Manual
IMPAX-SK Technologies
Force Curves
1
2
MAN
AUTO2
AUTO1
1 2 3
4
1. LCD color graphic display (5.7")
2. Function selection keys
(current function of each key is
shown in the symbol box above)
3. Timing signal indicators 1 and 2
4. Operating mode selection with
indicator LED:
• MAN - mode (manual/set-up)
• AUTO 1 - mode (normal shift)
• AUTO 2 - mode (after hour shift)
• STOP (machine switched off)
236
ABC
DEF
GHI
/min
1
2
3
JKL
MNO
PQR
4
5
6
STU
VWX
YZ
7
8
9
-/.
C
0
E
SK 1
SK 1
STOP
I M PA X - S K Te c h n o l o g i e s
8
7
6
5
5. Numerical keypad 0 - 9
(and optional alphanumerical entry)
6. E-key (Enter Key)
7. Key depressed together with the
MAN-key to allow change to the
sensor timing window. Enter new
start value and Press E-Key. Enter
new end value and Press E-Key.
8. C-key (Clear/change display mode,
Etc.)
1
Turn On (push button located on rear panel)
The display and the MAN-key light up. The
and check your parts. When okay, start the monitoring mode (Step 2):
2
Press AUTO-key
Unit will move into automatic monitoring mode (green AUTO-light turns on). During
the first few machine cycles the monitoring limits (envelopes) will adjust to fine tune.
3
Process Failures (machine stops)
In case of process errors (e. g. force errors or counter stops), the machine will be
IMPAX-SK 5
stopped by the
(the
on). The display's top line turns red and shows the error message and the time when
stopped.
4
Re-start after machine stop
MAN
- press the
-key (stop relays are released so machine can be jogged)
- eliminate the cause of the stoppage, re-start machine and check parts
AUTO
- when parts are ok, press
C
Set the part counters
C
- press function key
(counter C1 for order size will appear)
C
- to set press
(old value turns blue) and enter your desired new count
E
- confirm your entry with
. Actual count zeroes, confirm again with
- press any key to switch counter from stop active ( ) to not active (-)
2
3
4
- use the buttons
,
or
E
Set Sensitivity (S) ,Tolerance (
- Press
and then a numbered key to move to the desired channel
C
- to adjust settings press the
sensitivity (S)
- adjust envelop
setting (1=coarse, 9=fine, 0=channel is off) confirm with
Tol.
- adjust
(1-9 allowed faults, 0= immediate stop) and confirm with
QL
- adjust
(Quality Limit) to minimal acceptable limit and confirm with
IMPAX-SK 5
is ready. Start the machine
AUTO
light turns off and the red STOP light comes
again to return to monitoring mode
to call up the other counters and then set them
Tol
) and QL (Q-Limit)
key (the sensitivity box will turn blue)
E
E
E
E
