Synthesizers and Samplers
MONOPOLY

Equipment required

1. Small insulated trimmer screwdriver.
2. Guitar tuner

Preparation

Set the MONOPOLY controls as follows:
• Set MASTER TUNE, TUNE of VCO2, 3, 4 to the middle position
• PORTAMENTO to 0
• DETUNE to 0
• All OCTAVE to 8'
• WAVEFORM select the triangle waveform
• CUTOFF to 10
• RESONANCE to 0
• EG INTENSITY to 0
• KBD TRACK to 0
• VCA EG: ATTACK and DECAY set to 0, SUSTAIN and RELEASE set to 10
• NOISE to 0
• BEND and MG1 INTENSITY to 0
• Turn off the ARPEGGIATOR and EFFECTS
• Set key assign mode to MONO(UNISON)
• Set the OUTPUT VOLUME to 10 (switch to HIGH)
Connect the guitar tuner to the rear panel output.
Connect the power and hold the HOLD and EFFECTS buttons while you power on the unit. This important step will set
the unit back to its factory calibrations before you can begin the calibration procedures below.
Leave the unit turned on for approximately 30 minutes. This will allow the circuits time to warm up and the
components and performance to stabilize with temperature. Without this warm-up time, the calibrations will be
inaccurate.
