Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXCRART21-RUS PART DESCRIPTION Warning Label NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST) -
Page 6: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # AXCRART21-RUS HARDWARE DESCRIPTION CAM LOCK PIN ALLEN KEY SCREW CAM LOCK M6 X 30mm ALLEN KEY QTY 30 SETS QTY 6 QTY 1 PHILLIPS SCREW ROUND HEAD M4 X 15mm QTY 36 Required - Flathead screwdriver Phillips screwdriver Not Included NEED HELP? For help with assembly or if you are missing a part,... - Page 8 1. Attach Bottom Dividers C to Bottom Shelf E using Allen Key Screws 1 through guide holes. 2. Use Allen Key 3 to tighten Screws and Bolts. Do not over-tighten.
- Page 11 2. Insert three Cam Locks 2 into guide holes on each part D , E . 3. Use Phillips screwdriver to secure Cam Locks. Do not over-tighten...
- Page 14 2. Insert three Cam Locks 2 into guide holes on each part BL , BR , C2 . 3. Use Phillips screwdriver to secure Cam Locks. Do not over-tighten...
-
Page 18: Warranty
WARRANTY...
