My Apple AirPlay audio is interrupted by short breaks

• Make sure the Apple device is not covered or obstructed.
• Make sure the Apple device has a good connection to the same Wi‑Fi network as the stereo.
• Make sure the Apple device is not connected to the stereo using Bluetooth technology and Wi‑Fi.
Using both a Bluetooth and a Wi‑Fi connection may cause playback interruptions.

Specifications

General
Weight
Water resistance
Operating temperature range
Storage temperature range
Input voltage
Current (max.)
Current (muted)
Current (off)
Fuse
Wi‑Fi wireless range
Bluetooth wireless range
Wireless frequencies/protocols
Compass-safe distance
On-board, Class D Amplifier
Output music power per channel
Total output peak power
Output power per channel
Tuner frequencies
Tuner
FM radio frequency range
FM frequency step
AM radio frequency range
AM frequency step
1
The stereo may limit the output power to prevent the amplifier from overheating, and to maintain the audio dynamics.
Appendix
340 g (12.0 oz.)
IEC 60529 IPX7 (front of stereo only, when properly installed)
From 0 to 50°C (from 32 to 122°F)
From -20 to 70°C (from -4 to 158°F)
From 10.8 to 16 Vdc
8 A
Less than 400 mA
Less than 200 mA
15 A blade type
Up to 32 m (105 ft.)
Up to 10 m (30 ft.)
Wi‑Fi 2.4 GHz @ 15 dBm nominal
Bluetooth 2.4 GHz @ 10 dBm nominal
10 cm (3.9 in.)
70 W max. x 2 at 2 ohm per channel
140 W max.
2 x 43 W RMS at 14.4 Vdc input, 2 ohm, 10% THD
1
2 x 26 W RMS at 14.4 Vdc input, 4 ohm, 10% THD
Europe and Australasia
87.5 to 108 MHz
50 kHz
522 to 1620 kHz
9 kHz
USA
Japan
87.5 to 107.9 MHz
76 to 95 MHz
200 kHz
50 kHz
530 to 1710 kHz
522 to 1620 kHz
10 kHz
9 kHz
21
