  • Page 1 ® Bose Computer MusicMonitor™ ©2007 Bose Corporation Service Manual Reference Number 301248-SM Rev. 03 Electronic Copy Only...

  • Page 2: Table Of Contents

    Duracell, Eveready, Energizer, Maxell, Toshiba or Shun Wo CR2032 or DL2032 3-volt lithium battery. CAUTION: The Bose Computer MusicMonitor™ contains no user-serviceable parts. To prevent warranty infractions, refer servicing to factory service. PROPRIETARY INFORMATION THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF...

  • Page 3: Safety Information

    SAFETY INFORMATION 1. Parts that have special safety characteristics are identified by the symbol on schematics or by special notes on the parts list. Use only replacement parts that have critical characteristics recommended by the manufacturer. 2. Make leakage current or resistance measurements to determine that exposed parts are acceptably insulated from the supply circuit before returning the unit to the customer.

  • Page 4: Warranty

    Entering Demo Mode: Turn on the Computer MusicMonitor™ Press and hold the volume up button until the volume reaches maximum and the LED starts to blink. Continue to hold the volume up button (approximately 30 seconds) until the LED stops blinking, which indicates that the Speaker System has entered demo mode.

  • Page 5: Specifications

    SPECIFICATIONS Mechanical Dimensions: Individual Speaker: 4.8“ H x 2.5” W x 4.8” D (12.2 x 6.5 x 12.3 cm) Weight: Right Speaker: 1.3 lbs (1 kg) Left Speaker: 1.2 lbs (.8 kg) Electrical Power Pack Rating: Input Voltage Range: 100VAC to 240VAC Input Frequency Range: 50/60 Hz AC Input Current:...

  • Page 6: Packaging Part List, Bose

    PACKAGING PART LIST Bose ® Computer MusicMonitor™ ® Item Description Bose Part Product Note Number Code PACKING, THERMOFORM, TOP 309359 PASSIVE SPEAKER ASSY, LEFT 301482-001 *PASSIVE SPEAKER ASSY, LEFT, JAPAN 301482-003 POWERED SPEAKER ASSY, RIGHT 301481-001 *POWERED SPEAKER ASSY, RIGHT, JAPAN...

  • Page 7: Listening Test Procedure

    LISTENING TEST PROCEDURE Test Equipment required: Audio Signal Generator Test Set up a. Connect speaker cable from the left speaker to the right speaker. b. Connect a signal generator to the audio input cable and connect the cable to the input jack on the right speaker.

  • Page 8: Service Manual Revision History

    SERVICE MANUAL REVISION HISTORY Date Revision Description of Change Change Driven By Pages Level Affected 08/16/07 00 Document released at Service Manual revision 00 release 11/09/07 01 Part number changes for the remote control and DVD demo disc. 12/18/07 02 Deleted audio cable part The Computer number.
  • Page 9 SPECIFICATIONS AND FEATURES SUBJECT TO CHANGE WITHOUT NOTICE Bose Corporation The Mountain Framingham Massachusetts USA 01701 301248 P/N: -SM Rev. 03 8/2007 (H) http://serviceops.bose.com...
