- Page 1 Assembly Instructions & User’s Manual Style #166044 7 ft Trampoline with Sunshade Please keep this instruction manual for future reference Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily) Live Chat at: www.academy.com Email: customerservice@academy.com (Made in China)
-
Page 2: Table Of Contents
Table of Contents Warnings Basic Trampoline Skills Tools and Parts Assembly Instructions Care and Maintenance Warranty Information Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged, do not attempt to assemble the unit. -
Page 3: Warnings
Warnings IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read and follow all warnings, precautions, and instructions in this manual before assembling and using the trampoline. This product is intended for use by children above 3 years of age. This enclosure is to be used only in connection with this trampoline. -
Page 4: Basic Trampoline Skills
BASIC TRAMPOLINE SKILLS Fundamental Bounce Knee Drop 1. Start from a standing position with your head 1. Start bouncing from a standing position, erect and your eyes on the frame pad. keeping your eyes on the frame pad. 2. Swing your arms forward and up in a circular 2. - Page 5 Seat Drop Front Drop 1. Start from a low bounce and land on the bed 1. Land in a sitting position with your legs in a prone position. parallel to the bed. 2. Keep your head up and your arms extended 2.
-
Page 6: Tools And Parts
Tools Required Page 6 of 23... - Page 7 Page 7 of 23...
-
Page 8: Assembly Instructions
Assembly Instructions Step 1: You will need the following parts to complete section 1: 6 x Top tube with T-connector - Part A 6 x Straight leg - Part B 6 x Plastic foot cap - Part C 6 x Self-tapping screw - Part J Step 2: First we will complete one of the sections of the trampoline frame. - Page 9 Assembly Instructions Step 3: This step will require 2 people who must be wearing gloves. Slot two of the frame sections together as shown in the diagram. Step 4: Important: Ensure all of the top tubes, leg extensions and center legs are fully inserted. Page 9 of 23...
- Page 10 Assembly Instructions This step will require 2 people who Step 5: must be wearing gloves and protective eye wear. Lay the stitched bed (with the V- rings) part D out inside the frame of the trampoline. Locate the12 V-rings on corners. These will be at 60º...
- Page 11 Assembly Instructions Step 7: Attach a spring to the opposite of V-ring. IMPORTANT: You will now need to use the spring tool (part F) to attach the spring to the frame. Hook the spring tool onto end of spring, and pull until the spring can be slotted into the spring slot on the top of the frame.
- Page 12 Assembly Instructions Step 9: This step will require 2 people. Lay the frame pad - part G out over the edge of the frame with the ties facing downwards. Align the openings in the frame pad with the T-connector's on the frame. The frame is fully assembled now .
- Page 13 Assembly Instructions Step 11: Lay the enclosure netting out on the trampoline. Step 12: Find the sleeves that run along the middle of the enclosure netting. Page 13 of 23...
- Page 14 Assembly Instructions Step 13: Slot the thin sections on the black G3 poles into the metal ends so the poles become two long sections. Slot the Black G3 poles through the sleeves on the middle of the enclosure netting. You will now join the two ends of the Step 14: Black G3 poles together with the fitted pole connector, this will require two...
- Page 15 Assembly Instructions Step 15: As soon as the poles are bent enough, insert the connectors into the socket on the other pole (1). Push the pin inwards (2) and fully insert the connector. Ensure the pin is protruding through the slot in the socket.
- Page 16 Assembly Instructions Step 17: Slot the six bottom enclosure tubes into enclosure netting lower sleeves. Step 18: Slot the bottom enclosure tube into the tubes in the T-connector visible through the slots in the frame pad. Page 16 of 23...
- Page 17 Assembly Instructions Step 19: Slot the six top enclosure tubes into enclosure netting upper sleeves. Step 20: Slot the thin end of one of the bottom enclosure tubes into the open end of one of the top enclosure tubes. Align the hole in the bottom enclosure tube with the slot in the top enclosure tube.
- Page 18 Assembly Instructions Step 21: Screw one of the self tapping screws through the slot in the top enclosure tube and into the hole in the bottom enclosure tube using the cross-head screwdriver. Repeat for the remaining enclosure poles. Step 22: Find the ROD on top of enclosure netting.
- Page 19 Assembly Instructions Step 23: Attach the remaining exposed sections of the rods to the other enclosure tubes in the order shown in the diagram. The enclosure net will now be secured. Step 24: You will need the following parts 4 x Cords - Part M. Tie the end of the cord around one of the V-Ring attachments located on the mat.
- Page 20 Assembly Instructions Step 25: Slot the end of the cord through the middle of the next V-Ring or loop along. Now slot the end back through the net and down through the next V-Ring. Continue to do this until you have used up nearly all the cord then tie the end around a V-Ring.
- Page 21 Assembly Instructions Step 27: Slide Sunshade over top of trampoline enclosure mesh. Position the Sunshade loops so they align with the enclosure mesh poles. Tip: After the elastic cord go through the loop on sunshade then x on the enclosure pole as the image shown .
-
Page 22: Care And Maintenance
Care and Maintenance The following guidelines should always be observed. CARE Inspect the trampoline / enclosure before each use, and replace any worn, defective, or missing parts. Do not allow pets or animals on the trampoline or The following conditions could represent potential inside the enclosure, as claws may snag and pull the hazards and increase the danger of personal injury: bed material or damage the frame pad or netting. -
Page 23: Warranty Information
Warranty Information This product has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one year from the date of purchase.
