1. Product name and model

Intelligent LCD display for e-bike; model: YL81C.

2. Specifications

36V/48V power supply
Rated working current 15mA
Maximum working current 30mA
Leakage current at power-off <1uA
Working current at the supply controller end 50mA
Working temperature -20～60
Storage temperature -30～70

3. Appearance and dimensions

Fig. 3-2 Top View of Display 81C Dimensions
Fig. 3-1 Picture of Display 81C
1
Fig. 3-3 Side View of Display 81C Dimensions
