ASSEMBLY, MAINTENANCE, &

USER MANUAL

MODEL #SEK1200 / SEK1500

WARNING

Read all precautions and instructions in

this manual before using this equipment.

Save this manual for future reference.

Maximum user weight 200 lbs.

Skywalker Holdings LLC

P.O. Box 574, Brigham City, UT 84302

Table of Contents

Need help?

Do you have a question about the SEK1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Skywalker SEK1200

Page 1 ASSEMBLY, MAINTENANCE, & USER MANUAL MODEL #SEK1200 / SEK1500 WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Skywalker Holdings LLC Maximum user weight 200 lbs. P.O. Box 574, Brigham City, UT 84302...
Page 2: Table Of Contents
TABLE OF CONTENTS Part List...................................3 Part Identification..............................4 Exploded Drawing..............................5 Enclosure Net Removal............................6 Assembly...................................7-11 Other Accessories..............................12 Limited Warranty..............................13 STOP EVERYTHING YOU'RE DOING AND REGISTER YOUR TRAMPOLINE Find our warranty registration online by typing in: www.skywalkertrampolines.com/registration/ You'll need to have the following information handy: •...
Page 3: Part List
BEFORE YOU BEGIN Thanks for choosing Skywalker Trampolines! We’re just as excited as you are to help your family live an active (but most importantly FUN) lifestyle. This model is one of our favorites, and we’re confident you’ll love it too. To make things easier for you, we’ve listed important information that you (and your little outdoor adventurers) need to know.
Page 4: Part Identification
PART IDENTIFICATION Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares to the left (key numbers) will help you identify the parts during assembly. Straight Tube (x6) Curved Tube (x6) Enclosure Net (x1) Self-tapping Screw...
Page 5: Exploded Drawing
EXPLODED DRAWING...
Page 6: Enclosure Net Removal
ENCLOSURE NET REMOVAL STEP 1 First thing’s first... you’ll need to remove the end caps from the bottom of the sockets, and pull upwards to take down the enclosure poles. Helpful tip: When removing the enclosure poles, pull back on the middle of the poles! Once the enclosure poles are down, unscrew the bolts in the pole caps to remove the enclosure net from the pole caps.
Page 7: Assembly
ASSEMBLY STEP 1 Place the jump mat on the ground. The warning label should be on top, and the ID label should be on back. Now place the enclosure net on the jump mat, and make sure the first hole and the first V-ring line up. The first hole is the hole to the left of the enclosure door zipper.
Page 8 ASSEMBLY STEP 3 Now, repeat step 2 on the other side of the trampoline. Make sure to count the exact number of V-rings and frame holes so each one corresponds! Next, place a spring into the V-ring just left of the nearest T-joint, and stretch the spring until it reaches the frame hole just left of the T-joint.
Page 9 STEP 5 Now that you’ve installed the jump mat, place the frame pad on top of the springs. Adjust the frame pad so that the slits are directly above the T-sockets. Important: Don’t use the trampoline without the frame pad. It’s designed to protect your little jumpers! Trust us on this one.
Page 10 ASSEMBLY STEP 7 Insert one straight tube (3) into one curved tube (4), and secure with one self-tapping screw (6). Important: On the curved tube there is one end that has two holes. Make sure that end is on top! Repeat this step to attach the five remaining straight tubes and curved Self-tapping Screws (x6) tubes together.
Page 11 STEP 9 Starting from the enclosure door, lift one of the assembled poles and insert the straight tube (9) into the socket. Repeat this process to assemble the five remaining poles. Helpful tip: When inserting the enclosure poles, pull back on the middle of the poles! Then, insert the end caps into the bottom of the sockets.
Page 12: Other Accessories
OTHER ACCESSORIES Thanks for purchasing your replacement part from Skywalker Trampolines! Check out some of the other accessories we offer that will make your trampoline even more enjoyable! Find us online for more details: www.skywalkertrampolines.com SKYWALKER TRAMPOLINES WEATHER COVER ACCESSORY Protect your trampoline with the Skywalker Trampolines Weather Cover! This cover fits 12’...
Page 13: Limited Warranty
LIMITED WARRANTY Skywalker Holdings, LLC warrants its products to be free from defects in material and workmanship under normal use and service conditions. The steel frame is warranted for three (3) years after the date of purchase. All other parts are warranted for one (1) year after the date of purchase. Warranty coverage extends only to the original retail purchaser from the date of original purchase.
