OPERATION:

Audio/Video Input

Requires a 3.5mm to RCA audio/video cable (not included).
1. Connect 3.5mm jack to the AV input of unit.
2.
Connect RCA jack to stereo audio output and composite video of the
media player.
3. Set the projector's Source to AV and use the controls on the connected
player to select and play media.
AV IN
Connect AV cable (not included) to
media player's AV outputs.
Audio Left Channel - White
Audio Right Channel - Red
Video - Yellow
