- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 182525 5PC BAR SET REVISION 0 : 06/05/2020 REVISION 1 : 07/27/2020 PAGE 1 OF 9 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
182525 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
182525 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION PARTS IDENTIFICATION CHAIR LEFT FRAME CHAIR RIGHT FRAME CHAIR CROSSBAR 2PCS NOTE: QUANTITIES SHOWN ARE FOR ONE TABLE AND ONE STOOL HARDWARE IDENTIFICATION SHORT BOLT LARGE CAP 32PCS 4PCS (1/4" x 12mm SR) - Page 4 182525 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 9 COASTERFURNITURE.COM...
- Page 5 182525 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 5 OF 9 COASTERFURNITURE.COM...
- Page 6 182525 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 PAGE 6 OF 9 COASTERFURNITURE.COM...
- Page 7 182525 ITEM: ASSEMBLY INSTRUCTIONS STEP 7 STEP 8 COMPLETE PAGE 7 OF 9 COASTERFURNITURE.COM...
- Page 8 182525 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 1212 X 572 X 1080 H (MM) Product Size : 47.75" X 22.5" X 42.5" 1080 mm 1045 mm 42.5" 41" 715 mm 28" 270 mm 1090 mm 10.5" 43" 460 mm 18"...
- Page 9 182525 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 387 X 387 X 756 H (MM) Product Size : 15.25" X 15.25" X 29.75" 310 mm 390 mm 12.25" 15.25" 756 mm 29.75" 380 mm 300 mm 15" 11.75" 387 mm 387 mm 15.25"...
