nView Desktop Manager
SLI (Scalable Link Interface) technology allows users to install and benefit from two
PCI Express graphics boards in a single PC.
SLI Frame Rendering
Combines two PCI Express graphics boards with an SLI connector to transparently
scale application performance on a single display by presenting them as a single
graphics card to the operating system.
Benefits:
1. Visual simulation, broadcast, and video applications that are fill rate-limited will
benefit from using the split frame rendering (SFR) mode.
2. SPECviewperf and other applications that are geometry-limited will benefit from
using the alternate frame rendering (AFR) mode.
Requirements:
1. Two identical NVIDIA Quadro FX boards (5800, 5600, 4800, 4700X2, 4600, 3800,
and 3700)
2. SLI connector
SLI FSAA Mode
Combines two PCI Express graphics boards to drive one monitor with higher image
quality.
Benefits:
1. Expand single screen image quality (higher FSAA) : up to 32X FSAA
2. Example applications: VisSim (Flight, Architectural), Product/Industrial Design
review (Auto, Aero), some broadcast apps (VizRT, Brainstorm)
SLI Installation
Leadtek Quadro Series General Guide
1-25
