Page 1 Nova C Series Add Ons Nova C Single Endpiece...
Page 2 Product desription Recycling Assembly instructions Nova C Single Endpiece p3-5...
Page 3 Nova C Single Endpice Nova C Single Endpice can pe plaged at the end of any Nova C Back conﬁguration. Material Ribs: Form pressed vereer treated with hard wax oil. Material Legs: Powder coated steel. Nova C Add Ons Green Furniture Concept...
Page 4 Ribs and table tops are made of wood and adhesive and are sorted as combustible. Glides are made of HDPE and are sorted as plastic. Nova C Add Ons Green Furniture Concept...
Page 5 Bolt A x8 Screw A x94 to use a blanket or simmilar to prevent damage to the ribs and metal parts. Screw B x16 Bolt B x22 Nova C Add Ons Green Furniture Concept...
Page 6 Only three of the screws in the rest of Attach the Endpiece whit screw B. the conﬁguration should be replaced Replace the three screws that are with the new screws for the endpice. already in the Back Metal Strip. Nova C Add Ons Green Furniture Concept...
Page 7 Attach the Cover plate with Screw B. Replace the three screws that are Use screw A to conect the top of the already in the Metal Back Strip. Cover Plate to the Back rib. Nova C Add Ons Green Furniture Concept...
Page 8 greenfc.com...
