- Page 1 Nova C Series Manual...
- Page 2 Index Product description p3-5 Add ons Recycling Assembly instructions|Nova C Back p8-10 Assembly instructions|Nova C Back Double 4 seat p11-13 Assembly instructions|Nova C Back Double 5 seat p14-16 Assembly instructions|Nova C Bench p17-18 Assembly instructions|Nova C Back Armrest Assembly instructions|Nova C Bench Armrest Assembly instructions|Nova C Table Assembly instruction|Nova C Charger Maintenance &...
- Page 3 Product description Parts Slender ribs Wide ribs Nova C Back module Metal strip Metal legs Plastic Glides Nova C Bench module Slender ribs Wide ribs Metal strip Metal legs Plastic Glides Nova C Series Green Furniture Concept...
- Page 4 /concave 45 degrees. The bench modules are snapped together and locked with a draw- bolt catch. By opening the drawbolt catch the bench modules can be easily moved for annual cleaning or for reconfiguration. Nova C Series Green Furniture Concept...
- Page 5 Product description Apperance Nova C Series ribs The ribs and table tops are treated with hard wax oil which gives surface protection and color. Standard or custom colors can be chosen as well as color mixes. Special fire retardant treatment can be added.
-
Page 6: Product Description
Nova C Bench Armrest Nova C Bench Armrest can be placed in any slender rib of the Nova C bench. The default location is in the center of the bench module. Material: Powder coated steel. Nova C Series Green Furniture Concept... - Page 7 Glides are made of HDPE and are sorted as plastic. Charger casing is made of powder- coated steel and the outlet casing is made of ABS plastic. Chargers are sorted as electronic. Nova C Series Green Furniture Concept...
- Page 8 Due to that the assembly of this bench mostly is done with the ribs upside down we recommend you to use a blanket or similar to prevent damage to the ribs and metal parts. Drawbolt Catch x2 Nova C Series Green Furniture Concept...
- Page 9 The drawbolt catch should be aligned so that if the bench is turned Use screw B to attach the legs to the rib 180°, it should be able to be snapped together. construction. Nova C Series Green Furniture Concept...
- Page 10 Assembly instructions Nova C Back Use the drawbolt catch to snap the benches together. Nova C Series Green Furniture Concept...
- Page 11 Due to that the assembly of this bench mostly is done with the ribs upside down we recommend you to use a blanket or similar to prevent damage to the ribs and metal parts. Nova C Series Green Furniture Concept...
- Page 12 Use screw B to attach legs to the second rib construction, in the same manner as in picture Use screw A and metal clip to attach the ribs 4. Guide the ribs by means of the plugs. back-to-back. Nova C Series Green Furniture Concept...
- Page 13 The drawbolt catch Use the drawbolt catch to snap the benches should be aligned so that if the bench is turned together. 180°, it should be able to be snapped together.. Nova C Series Green Furniture Concept...
- Page 14 Due to that the assembly of this bench mostly is done with the ribs upside down we recommend you to use a blanket or similar to prevent damage to the ribs and metal parts. Drawbolt Catch x4 Nova C Series Green Furniture Concept...
- Page 15 Use screw B to attach legs to the second rib Use screw B to attach legs to the first rib construction, in the same manner as in picture construction. 5. Guide the ribs by means of the plugs. Nova C Series Green Furniture Concept...
- Page 16 Use screw A and metal clip to attach the ribs back-to-back. 180°, it should be able to be snapped together. back-to-back. Use the drawbolt catch to snap the benches together. Nova C Series Green Furniture Concept...
- Page 17 Due to that the assembly of this bench mostly is done with the ribs upside down we recommend you to use a blanket or similar to prevent damage to the ribs and metal parts. Nova C Series Green Furniture Concept...
- Page 18 The drawbolt catch should be aligned so that if the bench is turned Use the drawbolt catch to snap the benches 180°, it should be able to be snapped together. together. Nova C Series Green Furniture Concept...
- Page 19 Nova C Back Armrest Bolt B x4 Nova C Back Armrest x1 Metal plate x2 Screw-nut A x4 Assemble armrest with Bolt B, metal plate and Screw-nut A Use slender rib with pre-drilled holes. Nova C Series Green Furniture Concept...
- Page 20 Nova C Bench Armrest Bolt B x4 Nova C Bench Armrest x1 Metal plate x2 Screw-nut A x4 Assemble armrest with Bolt B, metal plate and Screw-nut A Use slender rib with pre-drilled holes. Nova C Series Green Furniture Concept...
- Page 21 Nova C Table x1 Metal plate x1 Screw-nut A x5 Use slender rib with pre-drilled holes. Use slender rib with pre-drilled holes. Metal plate Assemble table with Bolt B, Screw-nut A, Metal plate and Washer A Nova C Series Green Furniture Concept...
- Page 22 Assembly instructions Nova C Charger Nova C Charger x1 Tighten the screws on the back of the charger. Slide the charger onto the metal leg. Nova C Series Green Furniture Concept...
-
Page 23: Maintenance & Repair
Maintenance/Repair Background The Nova C Series wooden ribs are treated with hardwax Rubio Monocoat Oil Plus 2C, a maintenance series that is environmentally sound. We recommend that you use the Rubio Monocoats (Rubio) products for oiling to cleaning and maintenance, as these products are environmentally friendly and designed to be compatible at each stage. - Page 24 Cloths, saturated with oil, may spontaneously combust. After usage, they need to be soaked in water before disposal. 7: Remove all excess oil with a dry cloth. 8: Treated Dark Oak rib. Let dry for at least 12h. Nova C Series Green Furniture Concept...
- Page 25 If for any reason you need to change any of your ribs, it's easy to do. Unscrew the four screws that belongs to the Remove the damaged rib. damaged rib. Add the new rib. Screw the new rib in place. Nova C Series Green Furniture Concept...
- Page 26 greenfc.com...
