  • Page 1 Micro-C / Micro | User Manual...
  • Page 2 Micro-C / Micro | User Manual Technical specication : Micro-C Micro Technical Specications: Frequency range 68 - 28000 Hz+/-3 dB 70-28000 Hz +/-3 dB Sensitivity (2.83V / 1m) 84.5 dB 84.5 dB Nominal impedance 4Ω 4Ω Max SPL 100 dB 100 dB Recommended amplier...
  • Page 3 Micro-C / Micro | User Manual Frequency Response (Micro-C) 20kHz Frequency Response (Micro) 40.0 36.7 33.3 30.0 26.7 23.3 20.0 16.7 13.3 10.0 20kHz Response Curve : ------ (Blue) : on axis ------ ( Green ) : 15° off-axis ------ ( Red ) : 30°...
  • Page 4 Micro-C / Micro | User Manual...
  • Page 5 Micro-C / Micro | User Manual...
  • Page 6 Micro-C / Micro | User Manual ISOMETRIC VIEW (MICRO) 4in SB12PAC25-4 Or 4in SB12CACS25-4 (Sold separately) ISOMETRIC VIEW (MICRO-C)
  • Page 7 Micro-C / Micro | User Manual...
  • Page 8 Micro-C / Micro | User Manual Damping Material Position (dimensions in mm)
  • Page 9 Micro-C / Micro | User Manual...
  • Page 10 Micro-C / Micro | User Manual Part List (each cabinet): 1 pc - High frequency driver SB19ST-C000-4 (sold separately) ........1 pc - Low frequency drivers 4” SB12PAC25-4 or 4” SB12CACS25-4 (sold separately) 1 pc - Micro crossover kit (sold separately) ..............
  • Page 11 Micro-C / Micro | User Manual Assembly Instructions: 1. Take out the cabinet from the packaging and take out the raw damping material from the cabinet. 2. Unscrew the binding post nut then attach both binding post terminals on the rear of the cabinet.
  • Page 12 Micro-C / Micro | User Manual 4. Tighten the nut using 11 mm hex socket head. Put some glue around the nut to seal the cabinet. 5. Place the crossover on the rear panel inside the cabinet. 6. Secure the crossover to the cabinet with the four screws.
  • Page 13 Micro-C / Micro | User Manual 7. Connect both crossover input cables to the binding post terminals. 8. Cut the raw damping material according to the cutting diagram. 9. Place each part of the damping material the cabinet according to damping position diagram.
  • Page 14 Micro-C / Micro | User Manual 10. Attach the tweeter cables from the crossover to the tweeter terminals, then place the tweeter into the tweeter cutout on the cabinet, align the screw holes to the cabinet screw holes. 11. Attach the woofer cables from...
  • Page 15 Rev.0: (07.06.21)
