Summary of Contents for Bartec Auto ID TECH1000
-
Page 1: User Guide
Tyre Pressure Monitoring System Tool UIDE Camera Rubber housing On/Off: hold down for a few seconds Press once for more Display options Home: Back/Esc returns to Home menu Mini USB USB port Bartec Auto ID Ltd. SW Version: R.59.0 (English) 2019... -
Page 2: Foreword
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage 2) brouillage est susceptible d’en compromettre le fonctionnement. Bartec Auto ID Ltd. SW Version: R.59.0 (English) 2019... -
Page 3: Table Of Contents
Tyres and TPMS ................8 Service History ................12 Support ..................12 Training ..................13 Settings ..................13 Registration ..................14 Appendix ..................16 Technical Specification ..............18 Bartec Product Range & Accessories ..........19 Bartec Auto ID Ltd. SW Version: R.59.0 (English) 2019... -
Page 4: Important Notices
• Do not smoke or use naked flames when working on a vehicle. • Wear safety glasses to protect your eyes from dirt, dust or metal chips. Disposing of equipment Bartec Auto ID Ltd. SW Version: R.59.0 (English) 2019... - Page 5 12 months as of date of invoice (parts and labour) only if product has been correctly used. Serial number must stay readable and proof of purchase must be retained for presentation upon request. Bartec Auto ID Ltd Unit 9 Redbrook Business Park...
-
Page 6: Before Getting Started
ETTING TARTED 1. Charging NOTICE: Only use the power supply that is included in the TECH1000 tool kit to charge this tool. The use of un-approved power supplies may damage it and will void the tool warranty. 2. Registration The Bartec TECH1000 can be registered at https://tools.bartecautoid.com/... -
Page 7: Charging Tool
2019 HARGING The TECH1000 is shipped with a charged battery. It is recommended that the tool is charged 2+ hours before first use. For optimum performance, always keep it sufficiently charged. When there is an insufficient amount of power remaining in the battery, the TECH1000 will flash its battery icon for two seconds, save all of the TPM Data and then power itself off. -
Page 8: New Service
TECH1000 User Guide R.59.0 2019 ERVICE All menu items marked with an asterisk (*) are mandatory fields. VIN: Select whether the VIN should be read from the ECU or by the integrated camera. Choose from the following options: ▪ ▪... - Page 9 TECH1000 User Guide R.59.0 2019 Connect the OBD Module to the Vehicles OBD II port and connect the tool to the module. In case of any problems the troubleshoot menu will help you to obtain a connection. 2: S ENSOR...
- Page 10 TECH1000 User Guide R.59.0 2019 POSSIBLE READING SCENARIOS Note that if a faulty TPM sensor has been replaced, some methods of relearn procedures will need to be followed, as explained later in this manual. To receive further Sensor Information tap on one of the symbols next to the wheel position.
- Page 11 As soon as all measurements are taken, the data can be send to the Tech1000 by pressing the Bl Icon on the TAP100 [SCREENSHOT] . The Tech1000 will then show all data that was sent via the TAP100.
-
Page 12: Service History
Select a Service to see all the data from this job or to continue working on this vehicle. UPPORT If you have problems with your Tech1000 and the Troubleshooting was unsuccessful you can contact our Customer Support Team. 12 |... -
Page 13: Training
TECH1000 User Guide R.59.0 2019 RAINING In the Training Menu you can watch tutorials and Demonstrations of your tool and other tools of the Bartec range. Tap on the Play symbol to start the video. You can turn the volume up using the bar at the downside of the video. -
Page 14: Registration
PPENDIX APPENDIX A: Vehicle Identification Number VIN) When using the TECH1000 tool, it is important for the user to verify the Model Year to help insure looking for that proper sensor and using the proper vehicle COMs when Digit in necessary. - Page 15 “Park”, as otherwise it will not work on the vehicle. The TECH1000 tool has the ability to perform the necessary mode change. If a sensor is shown as “Ship”, “Test” or “Off” and the relearn toolkit provides the option “Set Sensor to Park Mode”, please use this option to change the sensor mode into the correct one: •...
-
Page 16: Technical Specification
TECH1000 User Guide R.59.0 2019 ECHNICAL PECIFICATION Power Supply 6000mAh Lithium Polymer rechargeable battery, not user serviceable Max power consumption 1.5W Schrader TPM, 0.5W all others Display LED colour touchscreen, 4.3 inch, 800x480 Input/output Mini-B style USB used to Connect to PC for firmware update and audit file download.
