Novanta SYNRAD Pulstar p100 Quick Start Manual

Pulstar p100/150 Water Cooled Laser Quick Start Guide
Important
See the Flyer 3D Marking Head and Pulstar p100/150 Laser Operators Manual for com-
plete installation details and instructions. A PDF version is available online at:
Note:
synrad.com/Manuals/manuals_laser.htm.
Read all Danger,
Hazard information) sections in the Operation Manuals mentioned above.

Unpacking:

Attention:
1
5
Important Caution! Unpacking the laser incorrectly can lead to damage that can void your
warranty. Keep All specially designed Foam and Packaging, you will need to re-use
Note:
it when moving your laser. Refer to this guide and the Technical Reference chapters in
the laser's Operation Manual when re-packaging for shipping and/or relocation.
Mounting feet and/or rails are optional, for complete details, refer to the laser's Operator's
on our website: www.synrad.com.
drawings
Caution! When re-packing the laser for relocation or shipment, use compressed shop air (less than
29 PSI) to blow out excess water from the cooling systems. Wear safety goggles! Nothing can be on
the sides of the laser at any time as damage will occur. The skin on the sides of the laser is fragile! All
box components must be stowed under the laser.
The wire harness &/or ports can be damaged in shipping if not re-packaged as shown above.
1
Warning, Caution terms, symbols, and instructions located in the (Laser Safety
For complete details, refer to the
our website. See the system inventory and mounting (sections) in your laser and
Flyer 3D Marking Head Operator's Manuals.
2
2. Locate the
wire harness in-
side the foam cap.
Correct
5. Correct way
to hold the laser.
Caution:
a Novanta company
Flyer 3D WMP7 Quick Start Guide
3
3. Push the wire
harness through
the slot.
Carefully lift the foam caps, one of
them has the wire harness that will be
damaged if pulled.
100/150
p100/150 Pulstar Water QSG version 3
http://www.
located on
4
4. Place the wire har-
ness on top of the
laser for lifting.
Manual and
