M211 BASE installation guide

Need help?

Do you have a question about the M211 BASE and is the answer not in the manual?

Page 1 M211 BASE installation guide...
Page 2 BASE Parts List – 1 of 2 2 x Support Legs (4 for King Size) 4 x Corner Rectangular Brackets 4 x Corner Triangle Brackets 2 x Middle Beam Support Bar Brackets (4 for King Size)
Page 3 BASE Parts List – 2 of 2 4 x Long Bolts & Nuts for Support Legs (8x for King Size) 10 x Long Bolts for Side Bar, 2 x Long Bolts for Middle Support Beam 20 x Medium Bolts 16 x Short Bolts...
Page 4 Join the 4 corners with the 2 brackets use shortest bolts for side panel, and medium bolts for end panels...
Page 5 Place the wooden leg underneath the triangle...
Page 6 Attach long metal bar on each side use 5 longest bolts to join the bar to the panel...
Page 7 Attach long middle bar onto of bracket as shown use 1 longest bolt on each end to secure tight...
Page 8 Attach support legs underneath the middle beam use 2 longest bolts with round nuts supplied...
Page 9 Insert all the wooden slats via plastic clip holders Connect the plastic clips to the wooden slat pieces Place metal support legs underneath the middle support beam, and fix using the long bolts and nuts provided Once all the plastic clips are attached to the wooden slats, push down onto the beams to lock in place...
