- Page 1 B308 / 309 Installation Guide...
- Page 2 Bed Frame Parts List – 1 of 2 2 x Support Legs (4 for King Size) 4 x Corner Rectangular Brackets 4 x Corner Triangle Brackets 2 x Middle Beam Support Bar Brackets (4 for King Size) 4 x Corner Black Feet...
- Page 3 Bed Frame Parts List – 2 of 2 4 x Bolts & Washers for Wing Attachment 4 x Long Bolts & Nuts for Support Legs (8x for King Size) 10 x Long Bolts for Side Bar, 2 x Long Bolts for Middle Support Beam 20 x Medium Bolts 16 x Short Bolts...
- Page 4 Join the 2 wing pieces to the headboard...
- Page 5 Unzip and slide 2 bolts for the wing pieces Unzip the back of the headboard Position 2 silver bolts with washer from inside the headboard as shown...
- Page 6 Align the holes on the wing with the silver bolts...
- Page 7 Install the brackets onto the bed frame Fix corners as shown – use shortest bolts for the Fix middle support bracket as side panel, and the medium bolts for the headboard shown – use medium bolts...
- Page 8 Install side metal bar onto the side panel Use 5 long bolts to join side metal bar to side panel Ensure the side panel and foot on each side panel are joined as shown...
- Page 9 Install the corner black feet Join the black plastic foot in each of the 4 corners underneath the triangle bracket as shown...
- Page 10 Attach the middle support beam on top of the bracket using the long bolt at each end...
- Page 11 Insert all the wooden slats via plastic clip holders Connect the plastic clips to the wooden slat pieces Place metal support legs underneath the middle support beam, and fix using the long bolts and nuts provided Once all the plastic clips are attached to the wooden slats, push down onto the bed frame beams to lock in place...
