5073 series bed frame installation guide

Confidential

Need help?

Do you have a question about the 5073 Series and is the answer not in the manual?

Page 1 5073 series bed frame installation guide Confidential...
Page 2 Join the 4 sides of the bed frame •  Attach 2 square brackets with the screws provided in each corner •  There should be 8 square brackets joining the sides •  Make sure not to fully tighten until final position is locked in The four corners of the bed frame are joined using 8 square brackets Confidential...
Page 3 Connect the metal feet to the foot board •  Attach the metal feet onto the end of the foot board with screws •  1 metal foot per footboard •  Ensure it is locked in first time round, as any subsequent movements will not make it as strong • ...
Page 4 Fix the support legs to corners of inner slat frame •  There should be 1 support feet in each corner of inner slat frame •  Unscrew the screw from the feet, and position in corner before rescrewing These 4 support legs go in each corner Confidential...
Page 5 Attach support feet and place into bed frame •  Attach support feet for middle beam •  King size will have 2 support beams •  Queen size will have 1 support beam •  Place inner slat frame into completed bed frame And your bed frame is now ready for use! Confidential...
