Tommy Swiss 105 Series Installation Manual

Bed frame

Download this manual

105 series bed frame installation guide

Confidential

Need help?

Do you have a question about the 105 Series and is the answer not in the manual?

Page 1 105 series bed frame installation guide Confidential...
Page 2 Join the 4 sides of the bed frame •  Attach 2 square brackets with the screws provided in each corner •  There should be 8 square brackets joining the sides •  Make sure not to fully tighten until final position is locked in The four corners of the bed frame are joined using 8 square brackets Confidential...
Page 3 Connect the side metal bar onto the bed side •  Attach the long metal bar onto the actual bed side using the screws provided •  Make sure not to fully tighten until final position is locked in •  Ensure square white brackets are secured before attaching the side metal bar The 2 metal bars will need to be attached to the 2 bed sides as shown above Confidential...
Page 4 Fix the support legs to the middle beam •  There should be 2 ‘T’ shaped support legs that support the middle beam •  Use 2 screws to lock in each ‘T’ shaped support leg The 2 ‘T’ shaped support legs need to be attached to the middle beam Confidential...
Page 5 Fix the middle beam to the head and foot board Attach to head board Attach to foot board The middle support beam needs to be attached from the middle of the head and foot board Confidential...
Page 6 Attach plastic holders to the wooden slats / fix the slats across the bed frame Fix slats across bed Attach plastic holders And your bed frame is now ready for use! Confidential...
