USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama LCD monitor.
We recommend that you take a few minutes to read carefully
through this brief but comprehensive manual before
installing and switching on the monitor. Please keep this
manual in a safe place for your future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite L403W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Iiyama ProLite L403W

Summary of Contents for Iiyama ProLite L403W

  • Page 1 All manuals and user guides at all-guides.com USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this...

  • Page 2: Table Of Contents

    To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE STATEMENT This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulation of the Canadian department of communications.

  • Page 3: For Your Safety

    STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock.

  • Page 4: Special Notes On Lcd Monitors

    Power Switch for hours. There is the possibility that the previous screen has been fixed. Pay attention sufficient when you use LCD Monitor. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.

  • Page 5: Before You Operate The Monitor

    * All guarantees and warranties are void for any problems or damage caused by a power cable not supplied by iiyama. OPTIONAL PARTS Optional parts as below are available for your LCD monitor. Please contact your local iiyama dealer or regional iiyama office for more details.

  • Page 6: Controls And Connectors

    All manuals and user guides at all-guides.com CONTROLS AND CONNECTORS INPUT AUTO MENU Down / Up POWER Front A Power Switch Auto Button / Return Button The monitor saves the power ON / OFF setting before the NOTE n For best results, use the Auto Set-up in conjunction Power Cable is disconnected.
  • Page 7 All manuals and user guides at all-guides.com Back Back J Handles K Speaker Input Terminal L Optional Tuner / Video Adapter Slot M DVI-I 29pin Connector (DVI) N Audio Connector for computer (AUDIO) O External Speaker Output Terminal (SPEAKER) P Audio Output Connector (AUDIO R/L) Q AC Connector (AC IN) R Main Power Switch (POWER) BEFORE YOU OPERATE THE MONITOR...

  • Page 8: Speaker Installation

    All manuals and user guides at all-guides.com SPEAKER INSTALLATION CAUTION Turn off the power switch and unplug the monitor before installation to avoid electric shock or damage. The speaker is heavy. Two person handling is recommended. Install the speaker on a stable surface. The monitor or the speaker may cause injury or damage if they fall or are dropped. Do not give a strong impact to the monitor or speaker.

  • Page 9: Connecting Your Monitor

    Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. Windows 95/98/2000/Me/XP Monitor Information File for iiyama monitors may be necessary for your computer and obtained via the Internet, using the address: http://www.iiyama.com (U.S.A.)

  • Page 10: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 16. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 12 for SCREEN ADJUSTMENTS.

  • Page 11: Adjustment Menu Contents

    All manuals and user guides at all-guides.com ADJUSTMENT MENU CONTENTS PC Analog / PC Digital Input Picture Control Adjustment Item Problem / Option Button to Press Too dark Brightness * Too bright Too dull Contrast Too intense Too far to the left H Position * Too far to the right Too low...
  • Page 12 All manuals and user guides at all-guides.com Function 1 Adjustment Item Problem / Option Upper Left OSD is displayed at upper left of the screen. OSD Position Upper Right OSD is displayed at upper right of the screen. Center OSD is displayed at center of the screen. Lower Left OSD is displayed at lower left of the screen.
  • Page 13 All manuals and user guides at all-guides.com Function 2 Adjustment Item Problem / Option Button to Press Adjust the picture quality at resolutions of less than Sharpness 1280 × 768 when selecting “On” at “Full Screen” on Function 1. Mode 1 (≈9300K) Bluish white (Approx.

  • Page 14: Screen Adjustments

    Auto Set-up, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the iiyama web site (http://www.iiyama.com or http:// www.iiyama.co.uk).

  • Page 15: Power Management Feature

    All manuals and user guides at all-guides.com 2) Stretch the right side of the picture frame to the right edge of the display area by adjusting the Clock. n When the left side of the picture frame moves apart from the left edge of the display area during the Clock adjustment, adjust NOTE steps 1) and 2).

  • Page 16: Trouble Shooting

    2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check The picture does not appear.

  • Page 17: Specifications

    All manuals and user guides at all-guides.com APPENDIX A SPECIFICATIONS ProLite L403W ProLite L323W Driving system a-Si TFT Active Matrix Panel Size Diagonal: 101cm / 39.6" Diagonal: 80.2cm / 32" Pixel pitch 0.6735mm H × 0.6735mm V 0.537mm H × 0.537mm V...

  • Page 18: Compliant Timing

    All manuals and user guides at all-guides.com ProLite L323W 978mm/38.5" 778mm/30.6" 136mm/5.4" 690mm/27.2" 300mm/11.8" 560mm/22.0" COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 37.861kHz 72.809Hz 31.500MHz 640 × 480 37.500kHz 75.000Hz 31.500MHz 37.879kHz 60.317Hz 40.000MHz SVGA 800 ×...

  • Page 19: Remote Control

    All manuals and user guides at all-guides.com APPENDIX B Optional TUNER / VIDEO Input APPENDIX B is available only when the optional Tuner / Video Adapter is installed in the monitor. For more details, please refer to the user manual for the optional Tuner / Video Adapter. REMOTE CONTROL CAUTION Do not use any other batteries other than those specified in this manual for the Remote Control.
  • Page 20 All manuals and user guides at all-guides.com I SLEEP Turn off the monitor automatically after selected period of time when antenna is connected. This is switched when you successively press the button as follows: 30min 60min 120min 0min(Off) J DISP Following information is displayed on the screen.

  • Page 21: Basic Operation

    All manuals and user guides at all-guides.com BASIC OPERATION n Turn on the monitor Monitor is turned ON and the Power Indicator turns to blue when you connect the Power [ Remote Control ] Press the Power Switch. Cable to the power supply. The monitor is turned OFF and the Power Indicator turns to orange when you press the Power Switch on the monitor or the Remote Control.

  • Page 22: Selection Of Tv Channel

    All manuals and user guides at all-guides.com n Display the adjustment menu page The menu page appears on the screen when you press the MENU Button on the monitor [ Remote Control ] Press the MENU Button. or the Remote Control. The menu page disappears when you press the Menu Button on the Remote Control again.

  • Page 23: Adjustment Menu Contents

    All manuals and user guides at all-guides.com ADJUSTMENT MENU CONTENTS TV / AV-1 / AV-2 Input Picture Control * (TV / AV-1 / AV-2) Adjustment Item Problem / Option Button to Press Too dark Brightness * Too bright Too dull Contrast * Too intense To adjust picture quality...
  • Page 24 All manuals and user guides at all-guides.com Function 1 (TV / AV-1 / AV-2) Adjustment Item Problem / Option Upper Left OSD is displayed at upper left of the screen. OSD Position Upper Right OSD is displayed at upper right of the screen. Center OSD is displayed at center of the screen.
  • Page 25 All manuals and user guides at all-guides.com Function 2 (TV / AV-1 / AV-2) Adjustment Item Problem / Option Film Mode is turned off. Film Mode To make a film picture such a movie natural without shakiness Enhancer is turned off. Enhancer To enhance the picture outline NOTE...
  • Page 26 B/G: West Europe I: U.K. , Ireland D/K: East Europe L: France For more details, please contact your local iiyama dealer or regional iiyama office. For the receivable channels on each Sound System, see Table for receivable channels. APPENDIX B...

  • Page 27: Teletext Function

    All manuals and user guides at all-guides.com TELETEXT FUNCTION n Switching of TELETEXT functions This is switched when you successively press the button as follows: TEXT mode MIX mode TV mode A black screen appears in TEXT mode when the received channel does not contain TELETEXT broadcasting. n Selection of the page Enter the page number by using the number button on the remote control in TEXT mode or MIX mode.
  • Page 28 All manuals and user guides at all-guides.com Table for receivable channels D / K B / G CATV CATV CATV CATV Freq. Freq. Freq. Freq. Freq. Freq. Freq. Freq. (MHz) (MHz) (MHz) (MHz) (MHz) (MHz) (MHz) (MHz) 48.25 105.25 IR A 45.75 105.25 55.75...
  • Page 29 All manuals and user guides at all-guides.com ENGLISH...
  • Page 30 All manuals and user guides at all-guides.com ENGLISH...
  • Page 31 All manuals and user guides at all-guides.com ENGLISH...
  • Page 32 All manuals and user guides at all-guides.com IIYAMA CORPORATION 710-1 Kitaowaribe, Nagano-shi 381-0014 Japan This manual is printed on recycled paper. Part No. 870Z238B02...
