Weatherproof Long-Life Battery Enclosure
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
General Information
The Model XB001 Weatherproof Long-Life Battery Enclosure is intended for use with the Model 13352,
13362, or 13372 Addressable Amplified Speaker Assemblies, the Model CP190 or CB191 RF Call Boxes
and/or the SPK200 Solar Panel Interface Kit. It includes the following components:
Qty
Description
1
Enclosure assembly
Screws, #10-32 × 1.125-inch
4
4
Washers
1
Wiring harness with weatherproof plug
Recommended accessories:
1
Model 230 Mounting Kit
1
Model 40201-008 Battery, 12V, 18Ah
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374
V
ISIT WWW
G A I - T R O N I C S ® C O R P O R A T I O N
A H U B B E L L C O M P A N Y
Model XB001
800-492-1212
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
Fax: 610-796-5954
Pub. 43004-033A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GAI-Tronics XB001
Summary of Contents for GAI-Tronics XB001
- Page 1 GAI-Tronics retains all intellectual property and other rights in or to the information contained herein, and such information may only be used in connection with the operation of your GAI-Tronics product or system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
- Page 2 Pub. 43004-033A Model XB001 Weatherproof Long-Life Battery Enclosure Page: 2 of 5 Installation Mounting the Enclosure 1. Remove the four screws from the front of the enclosure. Open the front cover to the left and pull straight out until the hinge pins separate from the rear section. Set the front door of the enclosure aside.
- Page 3 Pub. 43004-033A Model XB001 Weatherproof Long-Life Battery Enclosure Page: 3 of 5 3. Place the No. 40201-008 battery onto the mounting panel in the enclosure. Refer to Figure 2. The positive battery terminal should be on the right side when facing the enclosure.
- Page 4 Pub. 43004-033A Model XB001 Weatherproof Long-Life Battery Enclosure Page: 4 of 5 4. Connect the wiring harness’s quick-connect fastons to the battery terminals: red to positive, black to negative. Refer to Figure 3. 5. Return the door to the rear section by inserting the hinge pins and pushing into place, closing the door, and re-installing the four screws using 16 to 20 inch-pounds of torque.
- Page 5 Back out the two screws and separate the two sections, carefully setting aside the front section. Refer to GAI-Tronics Pub. 43004-030 for more detail. 2. Insert the lugged end of the (provided) weatherproof plug cable assembly through the existing cable bushing located on the bottom of the speaker housing’s rear section.
