LCN ST-2701 Installation Instructions

*27176*
27176
This product is not intended for use with conventional hinges or latching devices.
Do not remove spring tube from this product. Extremely
strong springs inside. if repairs are necessary, return to
1
Mount closer body in pocket according to dimensions shown on
template. Wall of pocket must be reinforced to ensure mounting of
body.
2
Mount rod and shoe on door according to dimensions shown on
template.
3
Place arm on closer shaft with main arm 35° to closer body (see
illustration). Do not rotate closer shaft. Secure arm to shaft with
arm screw.
4
With door in closed position:
1. Pull closer main arm away from door.
2. Slowly release arm and insert rod into forearm (see
illustration).
warning
factory.
ST-2701
5
Adjust arm to form slightly less than a 90° angle with door in
closed position. Secure with arm set screw. (see illustration)
6
Slowly open door into pocket. DO NOT FORCE if door will not
open completely. If door will not open completely into pocket,
adjust arm as shown in below illustrations.
1-877-671-7011
Installation Instructions
Customer Service
www.allegion.com/us
© Allegion 2014
Printed in U.S.A.
27176 Rev. 01/14-b
