Assembly Instructions -6Ft-
Tools Needed:
Hammer
(Preferred)
Pneumatic Brad Nailer
Power drill
Level
Power miter saw (Preferred)
3
pilot drill
32
Nail Set
Wood filler (Optional)
180 grit sand paper (Optional)
Tips:
1. Using pneumatic brad nailer will make assembly
quicker and easier.
2. Before opening any boxes, if multiple units and
different units have been ordered, please assemble
all boxes by units to ensure that specific unit parts
are not intermixed with other units.
3. It is highly recommended to drill
holes on back cross pieces for
before attaching to wall.
6ft Premier Cru
Kit Rack
Fasteners
1
1
finishing nails to
4
fasten cross pieces
1
1
brad nails if using
4
pneumatic brad nailer
1
#8x1
screws to attach
4
to other modules
#8x3
screws for attaching
racks to wall
3
dia pilot
32
#8x3
screws
Feb/22/2013
Toll Free: 1-888-253-6807
750ml Half Height Indiv. 6 Col
www.RosehillWineCellars.com
Countertop: optional
1
Advertisement
Related Manuals for Rosehill Wine Cellars 6ft Premier Cru Kit Rack
Summary of Contents for Rosehill Wine Cellars 6ft Premier Cru Kit Rack
- Page 1 Assembly Instructions -6Ft- Fasteners Tools Needed: finishing nails to Hammer (Preferred) Pneumatic Brad Nailer fasten cross pieces Power drill brad nails if using Countertop: optional Level pneumatic brad nailer Power miter saw (Preferred) #8x1 screws to attach pilot drill to other modules Nail Set #8x3 screws for attaching...
- Page 2 (5pcs)Middle ladder Counter top ( optional ) (1pc)Left end ladder (1pc)Right end ladder (5 pcs) Cross piece Baseboard 6ft Premier Cru Toll Free: 1-888-253-6807 Feb/22/2013 750ml Half Height Indiv. 6 Col Kit Rack www.RosehillWineCellars.com...
- Page 3 Step 1 Step 2 Attaching cross pieces to the BACK Attaching middle ladders. Place the right and left end ladders on the floor making sure Take the middle ladders making sure the angled cleats are facing front. Place each ladder into cross piece slots and nail from the the angled cleats are facing floor.
- Page 4 Step 3 Step 4 Attaching FRONT ladders. Attaching to the wall Nail the cross piece under the 5th cleat starting from Fasten to the wall through the back cross pieces using #8x3“ screws and the bottom. Nail the top cross piece from inside as using a level to make sure rack is mounted square on the wall.
