Summary of Contents for IQAir HealthPro Compact Plus
- Page 1 All manuals and user guides at all-guides.com HealthPro® Compact User’s Manual Swiss Made www. iqair. com...
- Page 2 All manuals and user guides at all-guides.com IQAir ® HealthPro ® Compact Goldach, Switzerland - home of IQAir’s production facility Filters awaiting final sealing process Filter quality control of a HyperHEPA® filter Control panel assembly Final system assembly Individual performance testing and certification Internal View IQAir®...
-
Page 3: Important Safety Instructions
© 2007 The IQAir® Group. All rights reserved. IQAir®, HealthPro® and HyperHEPA® are the registered trademarks of The IQAir® Group. V5-Cell™, PreMax™ and EvenFlow™ are trademarks of The IQAir® Group. IQAir® systems and filters are protected under U.S. patents 6 001 145 and 6 159 260. Other U.S., European and Asian patents pending. - Page 4 All manuals and user guides at all-guides.com...
-
Page 5: Table Of Contents
2. 1 Unpacking 2. 2 Choosing a Suitable Location 2. 3 Connecting to Power Chapter 3 – The IQAir® System’s Components 3. 1 Description of Housing Components 3. 2 Description of Removable Components 3. 3 How the IQAir® System Works Chapter 4 –... -
Page 6: Chapter 1 - Air Cleaning Systems And Indoor Air Quality
3. Ensure the IQAir® system can clean enough air to cope with your room size. The actual hourly air volume cleaned by the system should be at least double the air volume of your room. If the rate at which pollutants enter the room air is high or the indoor air quality requirements are stringent, the hourly air delivery of the system needs to exceed the room air volume several times.To achieve that level of air turnover, it may be necessary to employ more... -
Page 7: Chapter 2 - Setting Up
2.1 Unpacking To unpack the IQAir® system, open the top of the box and remove the square styrofoam pad which contains all accessories and product literature. Lay the box on its side, hold the system by the handle and pull it out of the box. -
Page 8: Choosing A Suitable Location
Do not use the IQAir® system when the power cord becomes damaged. The power cord may be replaced with an approved cord with a two-pole plug. -
Page 9: Chapter 3 - The Iqair® System's Components
3.1 Description of Housing Components The IQAir® system features a modular tower design in which all important filtration and air moving components are positioned vertically in-line, i.e. stacked on top of another. Air is drawn into the system at the base, and passes through several filter stages to be returned to the room via the diffuser on top of the system. -
Page 10: Description Of Removable Components
3.2 Description of Removable Components The IQAir® system features a modular housing design which enables the easy replacement of all filter elements in a matter of seconds. The illustration below shows all the removable components. For more details on how to replace filters, please refer to Chapter 6 –... -
Page 11: Chapter 4 - Using The Control Panel
Power Key The Power key switches the IQAir® system on and off. When the system is switched off, the fan stops to run, but the system will remain connected to the power supply (standby mode). The standby mode allows for automatic timer start-up. -
Page 12: Control Panel Locking Function
4.3 Fan Speed and Air Delivery The IQAir® system can be set to run at six different fan speeds which correspond to six different airflow rates. Speed 1 is the lower, speed 6 the highest fan speed.The higher the fan speed, the more room air will be filtered by the system. -
Page 13: Air Exchange Rates In Differently Sized Rooms
Any air cleaner can only be effective if it filters a sufficient amount of air in an indoor environment. For general air cleaning purposes, the IQAir® system should be able to filter the room air volume at least twice every hour on the set fan speed to achieve a significant air quality improvement. -
Page 14: Filter Life Monitor
4.4.2 Filter Life Monitor The IQAir® system is equipped with an electronic Filter Life Monitor that calculates the remaining life of the system’s filter elements. Thanks to the Filter Life Monitor, the user does not have to guess when filters need to be replaced or replace them at fixed intervals (which rarely correspond to the actual amount of use).The Filter Life Monitor watches... -
Page 15: Setting The Auto Timer
All manuals and user guides at all-guides.com Chapter 4 – Using the Control Panel 4.4.3 Setting the Auto Timer timer status field The Auto Timer Menu allows the setting of a Timer ON period, which is defined by a START time and an STOP time. For the Timer ON period, a fan speed can be selected in the Timer ON Fan Speed Menu (see 4.4.5). -
Page 16: Day-Of-The-Week Timer
All manuals and user guides at all-guides.com Chapter 4 – Using the Control Panel 4.4.4 Day-of-the-Week Timer The Day-of-the-Week Timer allows the deactivation of the Timer ON period on certain days of the week. In its default setting the Timer ON period is enabled on all seven days of the week.This is indicated by stars below the abbreviations of the days. -
Page 17: Timer Information In The Control Panel
All manuals and user guides at all-guides.com Chapter 4 – Using the Control Panel 4.4.6 Timer Information in the Control Panel The IQAir® control panel shows the timer status without the need to access the Timer related menus. Timer Deactivated Display’s Main Window Timer LED System on Standby: The first line shows the... -
Page 18: Time & Day Setting
Chapter 4 – Using the Control Panel 4.4.7 Time & Day Setting When the IQAir® system is first connected to the power, the day and time displayed will be incorrect and will have to be set for the timer function to work properly. -
Page 19: Changing The Airflow Units
Note:The air delivery (airflow units) displayed in this manual are examples only and will vary according to model. 4.4.10 Language Setting The Language Menu allows to change the IQAir® system’s display language. The languages from which you can choose will depend on the model and the country of purchase. -
Page 20: Chapter 5 - Using The Remote Control
(Battery Type: CR2025) Switching the System On and Off: To switch the IQAir® system on with the remote control, press any one of the speed control keys marked with 1 through 6. The system will still start at the fan speed of the pressed key. To switch the IQAir®... -
Page 21: Replacing The Remote Control Battery
Chapter 6 – Replacing Filters The IQAir® system is equipped with a Filter Life Monitor which is designed to assist in determining when a filter element needs to be replaced. If the air pollution in your environment is very high, there is a possibility that the filter elements may not be effective throughout the displayed life time and may have to be replaced earlier than indicated by the Filter Life Monitor. -
Page 22: Opening And Closing The Housing
Opening 6.3.1 Troubleshooting When Closing the Housing If the IQAir® system does not close properly, the upper part of the system may be offset against the lower part. To solve this problem, simply open both locking arms again, align the housing elements and push both locking arms in simultaneously. - Page 23 All manuals and user guides at all-guides.com Chapter 6 – Replacing Filters 4. Remove the filter clamps that secure the 5. Turn the frame upside down. 6. With the palm of the hand, press down filter in the frame by pulling these out of on the filter to loosen the filter from the the sliding grooves.
-
Page 24: Replacing The Hyperhepa® Filter (Filter 2)
For water soluble stains, use a window cleaning fluid. • For the removal of tough, non water soluble stains, use a silicon spray. • Do not use any solvents or any organic cleaning fluids. 7.2 Maintenance-Free Fan The IQAir® system is equipped with a maintenance-free fan motor. -
Page 25: Technical Support And Repairs
7.4 IQAir warranty Your IQAir HealthPro system comes with a warranty of 5 years on parts and labor. Please complete and return the enclosed warranty registration card soon after purchase. The information will allow us to provide you with a swift service should service work become necessary. -
Page 26: Technical Specifications
All manuals and user guides at all-guides.com Technical Information HealthPro Compact Plus Specifications Air delivery (per fan speed in m /h)* 1:35 cfm 2:60 cfm 3:100 cfm 4:130 cfm 5:150 cfm 6:200 cfm Weight (incl. filters) 26 lbs. Power requirements...
