IQAir HealthPro User Manual

H e a l t h Pro® S e r i e s
H e a l t h Pro® S e r i e s
User Manual
Table of Contents
Important Safety Instructions
Chapter 1 – Air Cleaning Systems and Indoor Air Quality
1. 1 Improving Indoor Air Quality
Chapter 2 – Setting Up
2. 1 Unpacking
2. 2 Choosing a Suitable Location
2. 3 Connecting to Power
2. 4 Fitting and Removing Casters
Chapter 3 – The IQAir® System's Components
3. 1 Description of Housing Components
3. 2 Description of Removable Components
3. 3 How the IQAir System Works
Chapter 4 – Using the Control Panel
4. 1 Description of Control Panel
4. 1. 1 Description of Control Panel Keys
4. 2 Control Panel Locking Function
4. 3 Fan Speed and Air Delivery
4. 3. 1 Regulating Fan Speed
4. 3. 2 Air Exchange Rates in Differently Sized Rooms
4. 4 Using the Menu Functions
4. 4. 1 Menu Overview
4. 4. 2 Filter Life Monitor
4. 4. 3 Setting the Auto Timer
4. 4. 4 Day-of-the-Week Timer
4. 4. 5 Timer ON/OFF Fan Speed Selection Menu
4. 4. 6 Timer Information in the Control Panel
4. 4. 7 Time & Day Setting
4. 4. 8 Filter Life Reset (New Filter)
4. 4. 9 Changing Airflow Units
4. 4. 10 Language Setting
4. 4 . 11 Current Model Setting
Chapter 5 – Using the Remote Control
5. 1 Remote Control Elements and Functions
5. 2 Getting the Best Transmission Results
5. 3 Replacing the Battery of the Remote Control
Chapter 6 – Replacing Filters
6. 1 Location of the Filters
6. 2 Ordering Replacement Filters
6. 3 Opening and Closing the Housing
6. 3. 1 Troubleshooting When Closing the Housing
6. 4 Replacing the PreMax Filter (F1)
6. 5 Replacing the V5-Cell Filter (F2) – HealthPro Plus Only
6. 6 Replacing the HyperHEPA Filter (F3)
6. 7 Discarding Used Filters
Chapter 7 – Maintenance
7. 1 Cleaning the Housing
7. 2 Maintenance-Free Fan
7. 3 Technical Support and Repairs
Chapter 8 – IQAir® Optional Accessories
Technical Specifications
Swiss Made
Page
1
4
4
5
5
6
6
7
9
9
10
10
11
11
11
12
12
12
13
13
13
14
15
16
16
17
18
18
19
19
19
20
20
20
21
21
21
21
22
22
22
23
24
24
24
24
25
25
26
27
3
Important Safety Instructions
About This User Manual
Congratulations on your purchase of this IQAir high-performance air cleaning system. Please study this user manual
carefully to familiarize yourself with the special features and functions of your IQAir system and keep it in a safe place
for future reference.
Read these instructions before using the air cleaner:
• Do not use this air cleaner as sole protection against harmful pollutants.
• Do not immerse the air cleaner in water or other liquids.
• Always disconnect the power from this air cleaner by unplugging the power cord before adding or removing parts
and before cleaning.
• Do not operate this air cleaner if it has a damaged cord or plug, if the motor fan fails to rotate, if it is not working
properly, if it has been dropped or damaged, or dropped into water.
• If the power cord of this air cleaner should become damaged, it may be replaced with a similar two-pole cord, as
is commonly used for computers and similar appliances. Replacement cords are available from IQAir.
• Only use this air cleaner for its intended purpose of air cleaning in non-industrial environments.
• Do not use this air cleaner in areas with very high concentrations of dust or powder to prevent the danger of dust
explosions.
• Do not use this air cleaner in explosive areas.
• Do not use attachments or filters not recommended by IQAir.
• Do not use outdoors.
• Do not obstruct the air inlet and air outlet of the air cleaner.
• Do not place the air cleaner on a soft surface such as a bed or other soft furnishings.
• Only use this air cleaner in an upright position.
• Do not place next to a humidifier.
• Keep the power cord away from heated surfaces.
• Save these instructions for future reference.
The IQAir Group reserves the right to change specifications contained in this document at any time and without prior notice.
© 2002-2013 The IQAir Group. All rights reserved. IQAir, HealthPro and HyperHEPA are the registered trademarks of The IQAir Group. V5-Cell, PreMax and
EvenFlow are trademarks of The IQAir Group. IQAir systems and filters are protected under U.S. patents 6 001 145 and 6 159 260. Other U.S.,
European and Asian patents pending.
2
Chapter 1 – Air Cleaning Systems and Indoor Air Quality
Chapter 1 – Air Cleaning Systems and Indoor Air Quality
1.1 Improving Indoor Air Quality
Air cleaning can play an important role when it comes to improving indoor air quality. However, it should be noted
that air cleaning should be used in conjunction with pollution source control and ventilation, wherever possible.
Strategy to improve indoor air quality
To tackle any indoor air quality problem, keep the following three-step strategy in mind:
1. Eliminate or reduce the air pollution source as much as possible. Source control is by far the most effective way to
improve indoor air quality, since it sets out to deal with air pollution at the point of origin.
2. Ensure that sufficient fresh air is entering the room from outside. Air cleaners are not a substitution for sufficient
ventilation. They are not able to reverse the conversion of oxygen (O
breathing and combustion processes.
3. Ensure the IQAir system can clean enough air to cope with your room size. The actual hourly air volume cleaned
by the system should be at least double the air volume of your room. If the rate at which pollutants enter the room
air is high or the indoor air quality requirements are stringent, the hourly air delivery of the system needs to
exceed the room air volume several times. To achieve that level of air turnover, it may be necessary to employ
more than one IQAir system, or employ an IQAir HVAC filtration system. (Refer to section 4.3.2)
Air Cleaning Results
Although air cleaners may be advertised and sold to be suitable for use in specific indoor environments and to deal
with specific indoor air quality problems, the manufacturer and distributors make no claim as to the specific air
cleaning results that are achieved under the user's individual operating conditions. The air quality improvements
that can be realized with the IQAir system (as with any air cleaner) in indoor environments depends to a significant
degree on circumstantial factors which are out of the control of the manufacturer or distributors. Important factors
which will influence the air quality improvements that can be achieved in an indoor environment with an air cleaner
include:
•
Type of air pollutants present and their filtration efficiency
•
Intensity of the pollutant source(s)
•
Pollutant concentration
•
Size of the indoor environment (room size)
•
Operating speed of the air cleaner
•
Number of air cleaners placed in the indoor environment
•
Saturation state of the filters in the air cleaner
Consult a qualified specialist to determine an effective and comprehensive indoor air quality strategy.
Caution: Intense concentration of pollutants may cause filters/cartridges to saturate or expire sooner than indicated
by the control panel.
4
105.10.10.10 / 1
) into carbon dioxide (CO ), caused by
2 2
