Parts Breakdown
Model FP-IT-0009-VT
Item No. Description
AH792 Scraper 9 for 47083
AH793 Base 9 Bril. for 47083
AH794 Neck 9 Oss. for 47083
AH795 Head 9 Bril. for 47083
AH745 Lever Flange 9 for 47083
AH796 Rod Lever 9 for 47083
AH747 Upper Ice Knob for 47083
AH748 Clutch Washer Lever 9 for 47083
AH749 Cam Thickness Washer 9 for 47083
61573 Cup Spring 12.2x25x0.7 for 47083
37151 Clutch Nut for 47083
AH750 Microswitch with Lever HRC for 47083
37152 Microswitch Cam for 47083
AH751 Din Rail Control Unit 9 for 47083
AH752 Coded Sensor N180 FB M18 for 47083
AH753 Head Screw Caps Set for 47083
AH797 Ventilation Sheet 9 for 47083
Switching Power Supply 24VDC 12W
AH756
for 47083
AH755 Control Unit NC 11 01 for 47083
47083
Position Item No. Description
00 AH798 Cover Compl. + Guarn. 9 for 47083
01 AH758 Cover Cap 9 for 47083
02 AH799 Magn. Unit Holder Lock 9 for 47083
03 AH760 Magnetic Unit Coded N 180 HA for 47083
04 16995 Shaft with Regular Knives for 47083
05 26125 Bowl for 47083
06 AH800 Pot Lift 9 for 47083
08 AH801 Pot Holder Block 9 for 47083
10 AH802 Show Commands C9 Inv. for 47083
Stainless Steel Button with Light Y10
11 AH765
for 47083
12 AH766 Stainless Steel Button Y10 for 47083
13 AH767 Potentiom Knob. D.24 for 47083
14 AH768 Power Wired for 47083
16 AH769 Rubber Grommet 9 for 47083
18 AH803 Pot Card 9 Y19 230 MN for 47083
22 AH804 Card Spacer 9 for 47083
24 AH805 Board Plate 9 for 47083
26 60295 Motor 110V 50Hz for 47083
28 AH806 Motor Slide 9 for 47083
Position Item No.
30 AH807
32 AH808
34 AH809
36 AH810
38 19359
40 AH811
42 AH812
44 AH813
50 AH814
52 AH815
54 AH816
56 AH777
57 AH778
59 AH817
60 AH779
62 AH818
64 AH819
70 AH820
72
14
Description Position
Long Foot Plate 9 for 47083 74
Short Foot Plate 9 for 47083 76
Complete Hub Pulley 9 for 47083 80
Driven Pulley 9 LAV for 47083 82
Belt for 47083 84
Bearing 6201 2RS for 47083 85
Transmission Pin 9 for 47083 86
Retaining Rings Din 471 D 12E for
87
47083
Belt Curtain Pulley 9 for 47083 88
Retaining Rings DIN 472 D 32I for 47083 89
Cover 9 for 47083 90
Foot 40x20 M8x23 for 47083 92
Power Cable Comp. Suko with PA244S
94
for 47083
Pot Scraper 9 for 47083 95, 105
Spatula Handle 9 for 47083 101
Spatula Arm 9 for 47083 102
Rubber Arm Spatula 9 for 47083 103
Supp. Scraper Pot 9 for 47083 104
