Parts Breakdown
Model FP-IT-0006-VT
Item No. Description
AH784 Scraper Spatula 6 for 47269
AH742 Base 6 Bril. for 47269
AH785 Neck 6 Oss. for 47269
AH744 Head 4-6 Bril. for 47269
AH745 Lever Flange 9 for 47269
AH746 Rod Lever 6 for 47269
AH747 Upper Ice Knob for 47269
AH748 Clutch Washer Lever 9 for 47269
AH749 Cam Thickness Washer 9 for 47269
61573 Cup Spring 12.2x25x0.7 for 47269
37151 Clutch Nut for 47269
AH750 Microswitch with Lever HRC for 47269
37152 Microswitch Cam for 47269
AH751 Din Rail Control Unit 9 for 47269
AH752 Coded Sensor N180 FB M18 for 47269
AH753 Head Screw Caps Set for 47269
AH786 Ventilation Sheet 6 for 47269
47269
Position Item No. Description
00 AH755 Control Unit NC 11 01 for 47269
Switching Power Supply 24VDC 12W
01 AH756
for 47269
02 AH757 Cover Compl. + Guarn. 6 for 47269
03 AH758 Cover Cap 9 for 47269
04 AH759 Magn. Unit Holder Lock 6 for 47269
05 AH760 Magnetic Unit Coded N 180 HA for 47269
06 AH787 Shaft with Regular Knives for 47269
08 37174 Bowl for 47269
10 AH761 Pot Lift 6 for 47269
11 AH762 Cooker Lock 4-6 for 47269
12 60295 Motor 110V 50Hz for 47269
13 AH763 Motor Slide 6 for 47269
14 AH788 Show Commands C6 Inv. for 47269
Stainless Steel Button with Light Y10
16 AH765
for 47269
18 AH766 Stainless Steel Button Y10 for 47269
22 AH767 Potentiom Knob. D.24 for 47269
24 AH768 Power Wired for 47269
Position Item No.
26 AH769
28 AH770
30 AH771
32 AH772
34 AH773
36 AH774
38 AH789
40 17764
42 AH776
44 AH777
46 AH778
48 AH779
50 AH780
52 AH790
54 AH782
56 AH791
57
12
Description Position
Rubber Grommet 9 for 47269 59
Long Foot Plate 6 for 47269 60
Short Foot Plate 6 for 47269 62
Pot 4-6 Board Y19 230 MN for 47269 64
6 Card Spacer for 47269 66
Variotr Hub Pulley for 47269 68
Complete Pulley Hub 6 for 47269 70
Belt for 47269 72
Cover 6 for 47269 74
Foot 40x20 M8x23 for 47269 76
Power Cable Comp. Suko with PA244S
80
for 47269
Spatula Handle 9 for 47269 81
Spatula Arm 6 for 47269 82
Pot Scraper 6 for 47269 83
Rubber Arm Spatula 6 for 47269 84
Supp. Scraper Pot 6 for 47269 85
