Omcan FP-IT-0004-VT Instruction Manual page 11

Model FP-IT-0004-VT
Item No. Description
AH741 Scraper Spatula 4 for 47261
AH742 Base 6 Bril. for 47261
AH743 Neck 4 Oss. for 47261
AH744 Head 4-6 Bril. for 47261
AH745 Lever Flange 9 for 47261
AH746 Rod Lever 6 for 47261
AH747 Upper Ice Knob for 47261
AH748 Clutch Washer Lever 9 for 47261
AH749 Cam Thickness Washer 9 for 47261
61573 Cup Spring 12.2x25x0.7 for 47261
37151 Clutch Nut for 47261
AH750 Microswitch with Lever for 47261
37152 Microswitch Cam for 47261
AH751 Din Rail Control Unit 9 for 47261
AH752 Coded Sensor N180 FB M18 for 47261
AH753 Head Screw Caps Set for 47261
AH754 Ventilation Sheet 4 for 47261
47261
Position Item No. Description
00 AH755 Control Unit NC 11 01 for 47261
Switching Power Supply 24VDC 12W
01 AH756
for 47261
02 AH757 Cover Compl. + Guarn. 6 for 47261
03 AH758 Cover Cap 9 for 47261
04 AH759 Magn. Unit Holder Lock 6 for 47261
05 AH760 Magnetic Unit Coded N 180 HA for 47261
06 61572 Shaft with Regular Knives for 47261
08 37158 Bowl for 47261
10 AH761 Pot Lift 6 for 47261
11 AH762 Cooker Lock 4-6 for 47261
12 60295 Motor 110V 50Hz for 47261
13 AH763 Motor Slide 6 for 47261
14 AH764 Show Commands Inv. for 47261
Stainless Steel Button with Light Y10
16 AH765
for 47261
18 AH766 Stainless Steel Button Y10 for 47261
22 AH767 Potentiom Knob. D.24 VT for 47261
24 AH768 Power Wired for 47261
Parts Breakdown
Position Item No.
26 AH769
28 AH770
30 AH771
32 AH772
34 AH773
36 AH774
38 AH775
40 17764
42 AH776
44 AH777
46 AH778
48 AH779
50 AH780
52 AH781
54 AH782
56 AH783
57
11
Description Position
Rubber Grommet 9 for 47261 59
Long Foot Plate 6 for 47261 60
Short Foot Plate 6 for 47261 62
Pot 4-6 Board Y19 230 MN for 47261 64
6 Card Spacer for 47261 66
Variotr Hub Pulley for 47261 68
Complete Hub Pulley 4 for 47261 70
Belt for 47261 72
Cover 6 for 47261 74
Foot 40x20 M8x23 for 47261 76
Power Cable Comp. Suko with PA244S
80
for 47261
Spatula Handle 9 for 47261 81
Spatula Arm 6 for 47261 82
Pot Scraper 4 for 47261 83
Rubber Arm Spatula 6 for 47261 84
Supp. Scraper Pot 4 for 47261 85
