QUICK ST ART
USER GUIDE
Download the latest version of the manual as well as other languages from www.corally.com.
Téléchargez la dernière version du manuel ainsi que d'autres langues sur www.corally.com.
Download de laatste versie van de handleiding en andere talen van www.corally.com.
Laden Sie die neueste Version der Anleitung sowie weitere Sprachen von www.corally.com herunter.
C-00191 Manual - Revised : 2021-09-21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Corally SKETER C-00191
Summary of Contents for Corally SKETER C-00191
- Page 1 QUICK ST ART USER GUIDE Download the latest version of the manual as well as other languages from www.corally.com. Téléchargez la dernière version du manuel ainsi que d’autres langues sur www.corally.com. Download de laatste versie van de handleiding en andere talen van www.corally.com.
-
Page 2: Read First
All Team Corally models guarantee a high quality of manufacture and performance that guarantees you a high satisfaction of use and services provided by the Team Corally. Always take the time to read the instructions carefully in order to follow all the procedures to use your RC model safely for you and for other people and property in the area. -
Page 3: Use Precautions
Take all necessary precautions before, during and after using your model. You are responsible for the safe assembly, mainte- nance and use of your model. In case of any questions, contact your local reseller or contact Team Corally support for assistance. LIPO BATTERY SAFETY PRECAUTIONS •... -
Page 4: Warranty
If material defects or manufacturing faults should arise in a product distributed or manufactured by Team Corally / JSP Group Intl bvba, and purchased by a consumer, we Team Corally / JSP Group Intl bvba acknowl- edge the obligation to correct those faults or defects within the limitations described below. This manufacturers warranty is in addition to, and does not affect, the legal or contractual rights of the consumer which arise from the purchase of such products. - Page 5 (siehe Datum auf dem Umschlag des Handbuchs). - Kijk op de corally.com website in de download sectie en zorg ervoor dat u de laatste versie van deze handleiding heeft (zie datum op de omslag van de handleiding) KIT CONTENT (Depends on the selected model)
-
Page 6: Car Components
CAR COMPONENTS Front Differential Front Shock Absorber Suspension Arm Anti-Roll Bar Steering Block Steering Link Steering Servo Battery compartment Receiver Box Centre Differential Brushless Motor Speed Controller (ESC) Power Switch Rear Suspension Arm Wheel Axle Rear Upright Camber Link Anti-Roll Bar Rear Shock Absorber Rear Differential... - Page 7 QUICK START GUIDE READ THE INSTRUCTIONS CHARGE THE BATTERY INSTALL 4x AA BATTERY CHARGER BATTERY MAKE SURE THAT ALL SCREWS AND NUTS ARE INSTALL THE BATTERY TURN ON THE TRANSMITTER (Always First) TIGHTENED PROPERLY. CONNECT THE BATTERY TO THE ESC CHECK THE FUNCTIONS CHECK THE RADIO SYSTEM RANGE SWITCH ON THE ESC...
- Page 8 • A little oil will flow out of surface. the shock absorber. FRONT REAR SILICONE OIL SPRING TENSION SILICONE OIL SPRING TENSION SHOCK PISTON OFF-ROAD 600CPS 600CPS 6 Holes Ø1.4mm BASHING 700CPS 600CPS 6 Holes Ø1.4mm FACTORY 600CPS 600CPS 6 Holes Ø1.4mm SPRING TENSION .www. corally.com/Chemicals/Silicone-Oils/...
- Page 9 SHOCK ABSORBER - EXPLODED VIEW Do not overtighten the Shock Cap to prevent deformation of the silicone Shock Bladder. C-00180-768 Shock Piston C-00180-133 C-00180-189 Set content (8PCS) Shock Piston - 6x1.4 C-31001-25 Shock Piston - 8x1.2 C-00180-768 C-00180-190 C-00180-164 Place all small parts on a screwdriver (Ø3mm) C-00180-134 and push them into the shock body.
-
Page 10: Differential Maintenance
Perform the same maintenance operations for the centre and rear differentials. Use the correct grade of silicone oil according to the operation. Use only Silicone Oil, never use any other types of oil. FRONT DIFF CENTRE DIFF REAR DIFF OFF-ROAD 20.000 50.000 10.000 FACTORY 20.000 100.000 20.000 www. corally.com/Chemicals/Silicone-Oils/... - Page 11 FRONT & REAR DIFFERENTIAL - EXPLODED VIEW C-3002-30-12 (4pcs) C-00180-153-X C-00180-205 C-3611-3-08-16-05 C-00180-179 (set) C-00180-687 Diff Assembly - Front / Rear - C-00180-182 43T Bevel Gear - 1 set C-00180-184 C-00180-178 C-00180-205 C-00180-183 C-00180-182 C-3611-3-08-16-05 C-00180-153-X C-00180-098 CENTRE DIFFERENTIAL - EXPLODED VIEW C-3002-30-10 (x4) C-00180-154-X C-00180-205...
-
Page 12: Gear Ratio
• Special hardened steel • CNC cut teeth for perfect teeth shape and concentricity • Module MOD1 • fits all cars with MOD1 gears (1/8 Scale) • for 5.0mm motor shafts www.corally.com/Pinions-Gears/Pinions-MOD1/ GEAR RATIO : 3.31 Km/h Km/h Km/h Km/h... - Page 13 FRONT DRIVE TRAIN - EXPLODED VIEW C-3004-40-04 C-00180-329 C-00180-117-1 C-00180-009 C-00180-122 C-00180-123-1 C-00180-207 C-3101-30 (x2) C-00180-009-1 C-3003-30-12 (2x) C-3611-3-08-16-05 (x2) C-00180-150 C-3003-30-10 C-3201-60 C-00180-555 C-00180-011 C-00180-360 C-3003-30-16 C-00180-149 C-00180-089 C-3201-60 C-3003-30-20 C-00180-012 (x2) C-00180-051 M4x10 C-00180-419 C-00180-055 (set) C-3611-3-08-16-05 (x2) C-3004-50-05 C-00180-155-X C-00180-322 (x2)
- Page 14 REAR DRIVE TRAIN - EXPLODED VIEW C-3003-30-12 (x2) C-3003-25-04 (x2) C-00180-653 (set) C-00180-656 C-3003-30-16 (x2) C-3611-3-05-11-04 (x2) C-3003-25-04 (x2) C-00180-653 (set) C-00180-654 (x2) C-00180-552 C-00180-297 C-3003-25-04 C-3213-30-5 (x4) C-3003-25-04 C-3002-40-20 (x2) C-3003-30-14 (x2) C-3002-40-16 (x2) C-3003-30-18 (x2) C-3101-40 C-00180-658 C-3002-30-12 C-3003-30-16 (x2) C-3003-30-12 (x2) C-3213-30-5...
-
Page 15: Chassis - Exploded View
CHASSIS - EXPLODED VIEW C-00180-662 C-3101-30 (x4) C-00180-669 C-3003-30-16 (x4) C-00180-661 C-3003-30-14 (x2) C-00180-665 (set) C-3101-30 (x2) C-3101-30 (x4) C-00180-660 (set) C-3101-30 (x4) C-00180-662 C-00180-660 (set) C-00180-660 (set) C-00180-664 (set) C-3003-30-08 C-00180-663 C-3003-30-16 (x2) C-3003-30-06 (x2) C-3101-30 (x2) (x2) C-3002-30-08 (x2) C-3003-40-22 C-3003-30-12 (x2) C-00180-655... -
Page 16: Spare Parts
SPARE PARTS C-00180-008 C-00180-009-1 C-00180-010 C-00180-011 C-00180-012 Hub - Rear - Composite - 1 pc HD Steering Block - Pillow Ball Suspension Arm - Lower - Rear Suspension Arm - Upper - Front Suspension Arm - Lower - Front - Composite - 1 pc - Composite - 1 pc - Composite - 1 pc Cup (2) - Front - Composite - 1 Set... - Page 17 SPARE PARTS C-00180-197 C-00180-200 C-00180-206 C-00180-207 C-00180-216 Anti-Roll Bar - 2.4mm - Front Anti-Roll Bar - 2.4mm - Rear Steering Rack Bushing - Steel Steering Block Arms - Alumini- Servo Saver Spring - 1 pc - 1 pc - 1 pc - 2 pcs um - 2 pcs C-00180-219...
- Page 18 Check the availability of spare parts on the website www.corally.com Visualisez la disponibilité des pièces de rechange sur le site web www.coally.com Sehen Sie sich die Verfügbarkeit von Ersatzteilen auf der Website www.corally.com an. Controleer de beschikbaarheid van reserveonderdelen op de website www.corally.com...
- Page 19 SPARE PARTS FRONT & REAR DIFFERENTIAL - SPARE PARTS 20K Oil Filled C-00180-687 C-00180-178 C-00180-179 C-00180-184 C-00180-205 Diff Assembly - Front / Rear - Diff. Bevel Gear 43T - Steel - Planetary Diff. Gears - Steel - Gear Diff. Pin - Steel - 2 pcs Diff.
- Page 20 SPARE PARTS SHOCK ABSORBER - SPARE PARTS Holes: 6x1.4mm Holes: 8x1.2mm C-00180-770 C-00180-164 C-00180-768 C-00180-078 C-00180-188 HD Shock End - Short - Com- Shock Shaft - 66mm - Rear - Shock Piston Heavy Duty - Shock Body Insert - Washer - O-Ring - Silicone - 4x8mm - posite - 4 pcs Steel - 2 pcs...
-
Page 21: Option Parts
OPTION PARTS Fit with C-00180-128-2 Fit with C-00180-130-2 Fit with C-00180-039 Fit with C-00180-041 C-00180-039 C-00180-041 C-00180-128-2 C-00180-130-2 C-00180-286 Steering Ball Cups - Composite Rear Camber Ball Cups - Outer Turnbuckle - M4 - 50mm - Turnbuckle - M5 - 50mm - Shock Spring - Soft - Rear - 1 set - Inner - 1 set... - Page 22 STEEL SCREWS LENGTH LENGTH LENGTH LENGTH HEX FLAT HEAD SCREWS HEX BUTTON HEAD SCREWS HEX SOCKET HEAD SCREWS HEX SET SCREWS DIN 7991 - STEEL - 10 PCS DIN 7380 - STEEL - 10 PCS DIN 912 - STEEL - 10 PCS DIN 916 - STEEL - 10 PCS NOMINAL LENGTH...
-
Page 23: Ball Bearings
NUTS NYLSTOP NUT NYLSTOP NUT - FLANGED NYLSTOP NUT LOW PROFILE NUT ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS STEEL - 10 PCS DIN 936 - STEEL - 10 PCS NOMINAL NOMINAL NOMINAL NOMINAL COLOR COLOR COLOR COLOR SIZE SIZE SIZE SIZE... - Page 24 ALUMINIUM WASHERS WASHER FOR SOCKET HEAD SCREW WASHER FOR BUTTON HEAD SCREW WASHER FOR FLAT HEAD SCREW ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS ALUMINIUM - 10 PCS FOR S/H FOR B/H FOR F/H COLOR COLOR COLOR SCREW SCREW SCREW C-3214-20-0 Gold...
-
Page 25: Declaration Of Conformity
Title/Titel/Titre : Ceo FEDERAL COMMUNICATIONS COMMISSION EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE JSP GROUP INTL BVBA / CORALLY, and is VALID ONLY for the equipment identified hereon for use under the Commission’s Rules and Regulations listed below. - Page 26 SPORT RACING - LIPO ELECTRONIC Discover our range of Precision CNC-Cut MOD-1.0 Team Corally - Sport Racing 50C - 4S or 6S - XT-90 - A range of high quality electronic equipment Pinions for motors with a ø 5.0mm motor shaft Hard Case for the best performance.
- Page 27 NOTE This manual is an edition of Corally, a division of JSP GROUP INTL nv, Geelseweg 80, B-2250 Olen, Belgium. This manual is protected by a copyright and nothing from this edition may be reproduced or used without any prior written authorisation. Whilst every effort has been made to ensure the accuracy of the information in this manual, errors creep in and Corally can accept no responsibility for failures, wrong specifications, accuracy of colours, losses or damages caused.
